About the IS200DSPXH2DBD
The IS200DSPXH2DBD is a device which is known as a drive DSP control board. This is a component in the Mark VI series by General Electric. The latest in the Mark line of gas and steam turbine controls, Mark VI and its predecessors are tasked with controlling all aspects of industrial turbine management. The IS200DSPXH2DBD is a type of printed circuit board or PCB. The Mark VI Turbine Control System Series encapsulating this IS200DSPXH2DBD product here, as it is known at length, exists with a specific series of possible functional applications in the control and management systems of General Electric-compatible gas, steam, and wind turbine automated drive assemblies. This has to be defined as quite the significant functional upgrade upon the rudimentary gas and steam turbine-based possible application range introduced with the previous industry-standard Mark V Turbine Control System Series of essentially the same full series title. This IS200DSPXH2DBD product's Mark VI Series is also valued for its nature as one of the final-developed GE Mark product series utilizing the patented Speedtronic control system technology.
Hardware Tips and Specifications
The IS200DSPXH2DBD is a mid-sized printed circuit board which contains a range of various electronic components. A large white connector port has been attached to the right edge of the IS200DSPXH2DBD. This connector port is solid white in color with a series of metal connector pins. Two (2) smaller connector ports which are black in color have been placed on the opposite end of the PCB. Sitting in the center of the IS200DSPXH2DBD are two (2) large black components which are made in the shape of squares. At each corner of the components is a white screw connected the devices to the circuit card. Two (2) components which are known as resistor networks have been situated between these two (2) square components. These resistor network are solid white. Each contains a group of small resistors which are aligned in a row. The total resistance of each resistor network is equivalent to the sum of the resistance of the resistors within. Two (2) additional resistor network are situated to the right of the large black components. Many integrated circuits have been connected to the surface of the board. These integrated circuits are black and range in size.
This IS200DSPXH2DBD printed circuit board product offering or PCB for short from General Electric was originally designed and manufactured specifically with the company's Mark VI Turbine Control System Series in mind, which means that it is unfortunately not well-contextualized online within any great wealth of originally-pertinent instructional manual materials. With this being the truth, the IS200DSPXH2DBD functional product number itself stands to serve as a decent functional source of IS200DSPXH2DBD Board hardware component and component specification information, as it codes for a number of relevant IS200DSPXH2DBD Board hardware qualities through a series of consecutive functional naming elements. For example, this IS200DSPXH2DBD product number in specific is started off by an inclusion of the dual-functional IS200 series tag delegating both this IS200DSPXH2DBD product's normal Mark VI Series assembly on top of its domestic location of original General Electric manufacture. Some of the other pertinent IS200DSPXH2DBD Board hardware qualities indicated in this manner include its:
- DSPX functional product acronym
- Group two Mark VI Series grouping
- Conformal PCB coating style
- Three-fold revision table
