About the IS200DSVOH1A
This IS200DSVOH1A GE printed circuit board was originally produced by respected industry giant General Electric, for use in their Mark VI Speedtronic Series of automated turbine control systems and turbine control system component parts. This DSVO-abbreviated product offering was actually originally-produced by GE Industrial Systems; a subsidiary company of General Electric responsible for the production of all Mark VI Speedtronic Series products. This printed circuit board or PCB for short is actually better definable by its stated functional description as a DIN-rail Mounted Servo Terminal Board. This IS200DSVOH1A Servo Terminal Board is actually a modified version of a pre existing Mark VI Speedtronic Series product; adding a singular, A-rated functional product revision to the GE Industrial Systems IS200DSVOH1 parent printed circuit board.
Hardware Tips and Specifications
Unlike many similar Mark VI Speedtronic Series product offerings, this IS200DSVOH1A Servo Terminal Board actually possesses quite the expansive selection of original, factory-issued instructional manual materials online; allowing for a fully-developed product page here. Before attempting to explain some of the unique hardware features adopted by this DSVO-abbreviated board, it is important to understand the intended functionality of the product. This IS200DSVOH1A PCB features on-board functions including high-frequency decoupling exactly the same to those featured on the TSVO module assembly. In addition to this, the IS200DSVOH1A terminal board makes use of two active pulse rate inputs for flow measurement several inputs and outputs for six unique LVDT position sensors, and two total servo outputs; all of which contribute to this board's designation as a servo terminal board.
Now that some of the intended functionality of this IS200DSVOH1A PCB has been explored, it is possible to contextualize some of its specific hardware choices. This DSVO-abbreviated board' primary noticeable hardware feature is its large, Euro-style terminal block, which is densely populated with I/O points for 36 total terminal connections. This terminal block is affixed to the base board of the IS200DSVOH1A module through the use of several screw connections, and is considered pluggable. This IS200DSVOH1A Servo Terminal Board does feature some customizable hardware in its assembly; in the form of manually moveable jumpers included for Servo coil current regulation purposes. Despite this model's regular IS200 assembly type, it does include a possible SCOM grounding output terminal connection in its assembly; affixed to this product's base circuit board through the use of six mounting screws. Some of the other, crucial hardware component elements present in the greater configuration of the IS200DSVOH1A board include:
- Two Servo Valve Coils
- Multiple Noise Suppression Filters
- Factory-drilled Installation Holes
- Cabling to the corresponding VSVO board
- Basic integrated circuits and voltage-regulating transistors and capacitors
Before making a purchase decision on this DSVO Din-rail Mounted Servo Terminal Board, it is important to realize that any information stored on this product page has been sourced primarily from instructional materials detailing the unrevised IS200DSVOH1 parent printed circuit board. Before making any final purchase on this IS200DSVOH1A Simplex DIN-rail Mounted Servo Terminal Board product offering from our new and reconditioned inventory here, it is critically important to call ahead to ensure that this IS200DSVOH1A Simplex DIN-rail Mounted Servo Terminal Board product will ship with its plastic back installation backplane attached, as this backplane is able to side off quite easily and may have been detached or not included by our busy circuit board technicians.
