About the IS200DSVOH1ABA
The IS200DSVOH1ABA is a small printed circuit board or PCB. This board is a component in the Mark VI series by General Electric or GE. The Mark VI series is the latest version of the Mark line of controls for gas and steam turbines. The Mark VI Turbine Control System Series containing this IS200DSVOH1ABA device here must be defined as quite the whole functional upgrade upon the Mark V Series of just about the same full extended series title that immediately preceded it, as the Mark VI Series added the alternative energy-focused wind turbine possible functional application onto the gas and steam turbine-based functional environments already established through the release of the Mark V. This IS200DSVOH1ABA product's Mark VI Series is additionally held in high esteem with the greater figurative automated industrial global marketplace for its status as one of the final-produced GE Mark product series to incorporate the patented Speedtronic control system technology into many products, with this technology first being seen in 1969's initial Mark I product series.
Hardware Tips and Specifications
The IS200DSVOH1ABA is a lengthy printed circuit board with numerous electronic components. In the center of the IS200DSVOH1ABA, there are two (2) long terminal blocks. Each of the terminal blocks contains a number of silver metal terminals. These terminal blocks are identified by the initials TB. Situated directly above the terminal blocks on the top are two (2) red light-emitting diodes or LEDs. To the left of these red LEDs is a small solid yellow capacitor. Placed at the top of the IS200DSVOH1ABA are two (2) connector ports. The largest is positioned in the center of the top border of the PCB. A smaller connector port is located right at the upper left corner of the IS200DSVOH1ABA. Each of these connector ports is black and they are mounted on silver metal. On either side of the IS200DSVOH1ABA, there is a collection of small black components which are shaped like squares. These components are diodes which are labeled with the letter D. Small silver and black resistors have been placed among the black diodes. Any capacitor, resistor, transistor, or diode in the normal Mark IV Turbine Control System Series assembly of this IS200DSVOH1ABA Servo Terminal Board exists as part of a greater voltage regulation strategy standardized to the Mark VI Series. One hardware element that is not standardized for this function is this IS200DSVOH1ABA product's various integrated circuits, which have been specialized for the IS200DSVOH1ABA product alone.
The IS200DSVOH1ABA is a small, long rectangular circuit board. These small circuit cards may also be referred to as daughter boards. These may be attached to the surface of larger boards to provide more functionality to the larger board. Given this IS200DSVOH1ABA printed circuit board product offering's low amount of originally-printed instructional manual materials available online, its IS200DSVOH1ABA functional product number itself can be leaned on as a decently-strong supplemental source of IS200DSVOH1ABA Servo Terminal Board hardware component and component specification information, as it actually codes for a series of relevant IS200DSVOH1ABA Board hardware details through a series of consecutive functional naming elements. For example, the IS200DSVOH1ABA product number here is started off through its inclusion of the dual-functional IS200 series tag delegating the IS200DSVOH1ABA PCB's normal Mark VI Series assembly as well as its domestic original GE manufacture location. Some of the other relevant IS200DSVOH1ABA Board qualities indicated in this fashion have to be defined as its:
- DSVO functional product acronym
- Group one Mark VI Series grouping
- Conformal PCB coating style
- Three-fold revision table
