About the IS200DSVOH2B
The IS200DSVOH2B is part of the GE General Electric Mark VI Turbine Control Series and functions in the system as a Simplex Din-rail Mounted Servo Terminal Board. There are always additional letters (revisions) reflected after the base part number of IS200DSVOH2B. However, many customers will order this terminal board using the base part number alone as the last two letters do not alter functionality in this specific case. The Mark VI Turbine Control System Series that this IS200DSVOH2B printed circuit board can be considered a component member of exists with a particular series of possible functional applications in the control and management systems of General Electric-compatible gas, steam, and wind turbine automated drive assemblies; this must be defined as quite the significant functional upgrade upon the existing Mark V Turbine Control System Series of just about the same full extended series title. This is because the later-produced Mark VI Series tacked the more alternative energy-based wind turbine possible functional application onto the gas and steam-based environments seen with the earlier Mark V Series.
Hardware Tips and Specifications
When installed in the Mark VI application, the IS200DSVOH2B connects to the VSVO card via two cables, 15-Pin and 37-Pin respectively. The DSVO board features the following components: Input/Output for Qty 6 LVDT Position Sensors, Qty 2 pulse rate Inputs that aid with flow measurement, and Qty 2 Servo Valve Outputs. Additionally, because cabinet space is often limited, the DIN rail design of the IS200DSVOH2B allows for multiple of these modules to be stacked vertically along the rail. While the H1B version of this simplex board did not have Class 1 Division 2 Certification, the H2B model does carry these certifications. Information about this board can be found in the GE manual GEH-6421C Mark VI System Guide in Chapter 9. If deeper troubleshooting analysis is needed, please contact an authorized technician with experience diagnosing faults/errors in Mark VI Turbine Control Applications. If repair or replacement is an option, please reach out to our sales representatives to receive a formal quotation on the IS200DSVOH2B.
This IS200DSVOH2B printed circuit board product offering is not actually surrounded by very many originally-printed instructional manual materials on the internet, with the body of this IS200DSVOH2B personalized product page here primarily being based upon a diligent visual inspection of the IS200DSVOH2B device itself thus far. With this being the case, the IS200DSVOH2B functional product number can also be singled out as an emergency supplementary source of IS200DSVOH2B Board hardware component and component specification information, as it codes for a series of relevant IS200DSVOH2B Board hardware qualities through a selection of consecutive functional naming elements. For instance, the IS200DSVOH2B functional product number begins with an inclusion of the dual-functional IS200 series tag responsible for delegating the IS200DSVOH2B PCB's normal Mark VI Series assembly version on top of its domestic original location of GE manufacture. Some of the other relevant hardware traits indicated in this manner include the IS200DSVOH2B Board's:
- DSVO functional product acronym
- Group 2 Mark VI Series grouping
- Conformal PCB coating style
- B-rated functional product revision
