About the IS200DTCIH1A
The IS200DTCIH1A is a component that is called a DIN rail contact input board. The IS200DTCIH1A is a type of printed circuit board or PCB. The IS200DTCIH1A was made by GE or General Electric as a part of GE’s Speedtronic Mark VI series. The Mark VI Series that this IS200DTCIH1A printed circuit board product belongs to is truly better-definable as the Mark VI Turbine Control System Series. This GE Mark product series, as you can probably tell based off of its full extended series name, pertains specifically to a specific set of functional applications in gas, steam and wind turbine control and management systems. This does represent a massive upgrade upon the Mark V Turbine Control System Series that came before, as this previously-developed product series iteration pertained originally to gas and steam turbine functional settings alone. This IS200DTCIH1A General Electric product;s greater Mark VI Series is addtionally held in high esteem on its greater automated industrial marketplace as it is one of the lastly-developed GE Mark product series to intentionally incorporate the patented Speedtronic control system technology into a wide range of its different options.
Hardware Tips and Specifications
The IS200DTCIH1A is a printed circuit board that is long and rectangular. On the right edge of the IS200DTCIH1A, one (1) long terminal block is positioned. The terminal block is marked with the designator TB1 for terminal block 1. The long terminal block covers the entirety of the right edge of the IS200DTCIH1A. This terminal block features thirty (30) silver terminals altogether. The IS200DTCIH1A features fifty-four (54) black components that are shaped like squares. Most of these square components are aligned in parallel rows on the surface of the PCB. The rest of the square components are sitting at the lower edge of the PCB arranged in pairs. Each square component can be identified by the reference designator D. There are fifty-four (54) of these components which are named D1 through D54. Two (2) integrated circuits that are small in size can be seen on the IS200DTCIH1A. The integrated circuits are shaped like squares and they may be identified with the designator U, from U1 through U2.
Many solid light blue resistors have been placed in rows on the IS200DTCIH1A. Many solid silver capacitors that are small in size are also seen on the IS200DTCIH1A. Along the left side of the IS200DTCIH1A, there is one (1) long connector port. The connector port features many points that can be used to connect an additional part to the IS200DTCIH1A. Any capacitor resistor, diode, or even specialized integrated circuit found in the normal Mark VI Turbine Control System Series assembly of this IS200DTCIH1A printed circuit board product offering has to be attributed as existing as part of a greater voltage limitation and suppression strategy standardized to the rest of this IS200DTCIH1A PCB product's Mark VI Turbine Control System Series. This IS200DTCIH1A product is not surrounded by a great amount of detailed instructional manuals for the purpose of this IS200DTCIH1A personalized product page here, which means that the IS200DTCIH1A functional product number itself can be adopted as a decently-strong source of IS200DTCIH1A Board hardware component and component specification information; coding for various relevant IS200DTCIH1A Board details in a series of consecutive functional naming elements. For example, the IS200DTCIH1A functional product number begins with an instance of the dual-functional IS200 series tag dictating this IS200DTCIH1A product's normal Mark VI Series assembly version on top of its more standardized domestic location of original General Electric manufacture. Some of the other relevant hardware qualities revealed through this medium include the IS200DTCIH1A Contact Input Board's:
- DTCI functional product abbreviation
- Conformal PCB coating style
- Group one Mark VI Series product grouping
- A-rated functional product revision
