IS200EACFG1ABC

About the IS200EACFG1ABC

The IS200EACFG1ABC is a type of printed circuit board or PCB for short. This device was created to be a part of the Mark VI series by General Electric or GE. Mark VI is the latest series in the Mark lineup from General Electric. These are tasked with controlling the operations of gas turbines in many different industries all around the world. The IS200EACFG1ABC is a small printed circuit board which may be called a daughter board. These small circuit cards can be added to the top of a larger board and expand its capabilities.

Though the IS200EACFG1ABC is small in size, it contains a number of various electronic components. Three (3) connector ports which are small and black with metal bases. These jumper ports are labeled with names like J514 and J509. Each of these contain nine (9) female connectors. Two (2) very small metal components are sitting on the right side of the IS200EACFG1ABC underneath the middle connector port. Another two (2) of these tiny metal components are positioned beneath the top connector port. Paired up with each of these small metal components there is a very small resistor which has bands that are blue and white. Underneath each of the three (3) small connector ports is a small solid yellow capacitor. A lengthy series of these yellow capacitors and banded resistors which are white, red, and black alternate on the right half of the IS200EACFG1ABC. These small components are broken into three (3) collections of sixteen (16) components each.
