About the IS200EBACG2A
The IS200EBACG2A is a component for the EX2100e Thyristor Control, which is the fourth generation of GE’s state-of-the-art control systems for hydro, gas, or steam industrial turbine control. The Mark VI Turbine Control System Series containing this IS200EBACG2A EX2100E Bridge AC Feedback Board printed circuit board product offering here must be designated to exist as quite the momentous functional upgrade upon the Mark V Turbine Control System Series of essentially the same full extended series name that was previously considered the industry standard. This is because the Mark VI Series added the wind turbine alternative energy-focused possible functional application onto the gas and steam-based applications seen earlier with the release of the Mark V Turbine Control System Series. This IS200EBACG2A EX2100E Bridge AC Feedback Board PCB's Mark VI Series is also generally desirable on relevant promotional markets given its status as one of the last-released GE Speedtronic control system technology-powered product series.
Hardware Tips and Specifications
This system is designed to work in conjunction with GE’s Mark VIe and Mark VI ICS as well as its HMI and LS2100e Static Starter module. The unit can also work with other DCS systems that support Ethernet Modbus. The system can be used on both new and existing systems. The IS200EBACG2A functions within the EX2100e and Mark VI as an EX2100 Bridge AC Feedback board. It is one of several boards that is interconnected with the system’s main control processor using HSSL or High-speed serial link communication protocol. Other boards that use this protocol include the UCSB, CSLA, HSLA, and ESYS boards. The IS200EBACG2A has transformers available for three-phase voltage measurements, which allows the module to control and synchronize SCR gating on the incoming ac line. Outputs are fanned via the EAUX board to M1, M2, and C. Please be aware that EBAC boards are available as G1 boards that can be used for nominal ac line voltages of 701 to 1400 V, and G2 boards for up to 700 VAC. Please be sure you are ordering the correct board for your system.
AX Control ships products multiple times a day from our North Carolina facility in order to fulfill your product needs as quickly as possible. If you would like to receive same-day shipment on your in-stock purchase, please order before 3 pm so we will have adequate time to process, pull, and properly pack your order for its journey. As a printed circuit board product offering developed for General Electric's now-legacy Mark VI Turbine Control System Series, this IS200EBACG2A EX2100E Bridge AC Feedback Board device is not surrounded online by any great amount of originally-produced instructional manual materials. With this being the case, the IS200EBACG2A EX2100E Bridge AC Feedback Board's unique functional product number itself can be introduced as a decent supplemental source of IS200EBACG2A EX2100E Bridge AC Feedback Board hardware component and component specification details, as it codes for a number of relevant IS200EBACG2A EX2100E Bridge AC Feedback Board hardware qualities through a series of consecutive functional naming elements. For example, this IS200EBACG2A EX2100E Bridge AC Feedback Board product number starts off with a dual-functional IS200 series tag that is both responsible for dictating this IS200EBACG2A EX2100E Bridge AC Feedback Board product's normal Mark VI Series assembly version as well as its domestic original GE manufacture location. Some of the other IS200EBACG2A EX2100E Bridge AC Feedback Board information revealed in this manner include its EBAC functional product acronym, its normal PCB coating style, its group two Mark VI Series grouping, and finally its singular A-rated functional product revision.
