About the IS200EBACG2ABA
The IS200EBACG2ABA is a board component produced originally as part of the EX2100e Thyristor Control system; a subseries of the greater Mark VI Turbine Control System Series. This is a 4th generation control system and is part of GE’s modern control offerings for steam, hydro, and gas industrial turbines. The EX2100e is often used along with GE’s Mark VI or VIe ICS, and is designed to fully integrate with these and other GE equipment like the LS2100e Static Starter Module. The EX2100e typically also works with user DCS systems through Ethernet Modbus communications. This IS200EBACG2ABA circuit board's greater Mark VI Turbine Control System Series however, as you may have been able to tell based off of its extended series name inserted here, is a broader GE Mark product series that has several specific intended applications in the control or management systems of GE-compatible and recently-popular wind, gas, and steam turbine automated drives.
Hardware Tips and Specifications
The IS200EBACG2ABA is used within the Mark VI/e and EX2100e as an EX2100 Bridge A/C Feedback card. This is one of multiple boards that interconnects with the system’s control processor via high-speed serial link protocol. Other boards using this communication protocol include the ESYS, UCSB, HSLA, and CSLA boards. The IS200EBACG2ABA uses transformers located on its surface to provide three-phase voltage measurements. This allows the module to sync and control SCR gating on incoming AC lines. The resulting output voltage is fanned through the EAUX board to M1, M2, and C controllers. This IS200EBACG2ABA device is actually not the original EX2000E Bridge AC Feedback Board manufactured by General Electric for the Mark VI Series, as that would have to be considered the IS200EBACG2 product of the same functional description noticeably missing this particular IS200EBACG2ABA iteration's full three-fold product revision history. This IS200EBACG2ABA product's functional product number can serve as a decently-strong source of IS200EBACG2ABA Board hardware information, given the Mark VI Series' legacy product series attribution. Some of the various hardware details embedded in functional naming chunks of this product number include this IS200EBACG2ABA PCB's:
- EBAC functional product acronym
- Normal PCB coating
- Group 2 product grouping
- Three-fold revision history
It is important to note that EBAC boards are actually available here in two different families: G2 boards like this one are typically used for nominal ac line voltages up to 700 V. If you need a board for higher voltages, please look at similar G1 boards. It is important to make sure you order the correct board for your particular system’s needs, as the boards are not interchangeable. For additional information about the IS200EBACG2ABA, refer to GE manuals and datasheets. AX Control maintains productions on-hand at our North Carolina facility for faster service to you. Please order before 3 pm for same-day shipment of in-stock products. This IS200EBACG2ABA device has to be considered a relatively-fragile model of Mark VI Series printed circuit board product, given the fact that it exists with a pretty component-bare base printed circuit board that is long and narrow when compared to other relevant Mark VI Series products. With this IS200EBACG2ABA device's component-bare base PCB surface in mind, it is true that the IS200EBACG2ABA Board may not receive the standard level of voltage suppression and limitation afforded to Mark VI Series products with the standard set of diodes, rectifiers, capacitors, resistors, and specialized integrated circuits.
