About the IS200EBKPG1ACB
The IS200EBKPG1ACB is a replacement board component card from General Electric. It is typically used within the EX2100 excitation system that works in conjunction with Distributed Control Systems like GE’s Speedtronic Mark VI, or other DCS systems that can connect via available communication capabilities. The Mark VI is designed by GE for the control of industrial turbine systems using hydro/gas/steam. This IS200EBKPG1ACB device's greater Mark VI Turbine Control System Series immediately followed the previous industry-standard Mark V Turbine Control System Series of a similar full extended series title also released by GE. The Mark VI Series that this IS200EBKPG1ACB device belongs to is seen as a massive functionality-minded upgrade, as it tacks the all-important alternative energy-based wind turbine functional product application onto the gas and steam-based functional environments already known well to Mark V Series products.
Hardware Tips and Specifications
The IS200EBKPG1ACB is used as a backplane connector board within the EX2100 excitation system. It has three different individual sections, one each designed to go to M1, M2 and the C controllers. These sections are designed with their own independent power supplies. Each IS200EBKPG1ACB board and its associated connected boards (DSPX, EMIO, ESEL, ACLA, EISB) are cooled by overhead fans. The IS200EBKPG1ACB is designed with both D-SUB connectors and DIN connectors that will accommodate both I/O interface cables and plug-in controllers. Additionally, the board is built with round DIN connectors for keypad interface cables, test rings, and power supply plugs. This IS200EBKPG1ACB printed circuit board product offering or PCB for short from General Electric is actually not the originally-developed device of its specific Mark VI Turbine Control System Series functionality. In truth, this would have to be deemed the IS200EBKPG1 parent PCB product notably not utilizing this IS200EBKPG1ACB device's:
- A-rated primary functional revision
- C-rated secondary functional revision
- B-rated artwork configuration revision
More information about the IS200EBKPG1ACB can be found through GE manuals, data sheets, and user guides, particularly the EX2100 manual and user guide and the EBKP manual (GEI-100460.) Please follow any handling instructions or warnings described in these publications, as some equipment in the Mark VI series can cause injury if improperly handled. Only well-trained technicians should try to maintain or replace this equipment. AX Control typically ships in-stock orders the same day we receive them. Our North Carolina facility holds millions of dollars of on-hand inventory so we can serve you as quickly as possible. Local customers are welcome to send their personal couriers to pick up their orders at our office. Please call ahead to complete your transaction so we can have your order pulled and ready. This IS200EBKPG1ACB product's IS200EBKPG1ACB functional product number additionally can be used to reveal several IS200EBKPG1ACB Board hardware insights, including this IS200EBKPG1ACB Backplane Board's normal Mark VI Series assembly version, EBKP functional product abbreviation, Group one Mark VI Series product grouping, normal PCB coating, and finally its three-fold revision table as mentioned above.
