IS200ECTBG1ADE

About the IS200ECTBG1ADE

The IS200ECTBG1ADE is designed to function as an Exciter Contact Terminal Card in the Mark VI Speedtronic series.  This was one of the final systems released by GE under the Speedtronic name for the management of steam and gas industrial systems.   A flexible system that can be used in a variety of applications, the Mark VI can be designed as either Simplex or TMR (triple modular redundant) form to meet the needs of both large and small systems.  The MKVI is the 3rd Speedtronic system to offer TMR control.

The ECTB terminal card is offered in two basic configurations.  The IS200ECTBG1ADE is used in redundant systems only.  If you are running a Simplex system, please refer to our ECTBG2 boards.

The IS200ECTBG1ADE has six auxiliary contact inputs.  These are powered by the M1/M2 power supplies.   The board also has four additional general-purpose (Form-C) relay outputs.   The Form C outputs are controlled by the nearby, connected EMIO board.  The IS200ECTBG1ADE has two more trip contact outputs that drive a customer lockout.

The IS200ECTBG1ADE has two terminal strips located along one edge.  Two three-position plugs are on the surface of the board.  Additionally, the board has three d-shell connectors for connecting cables along one long edge.   The board has been shaped (notched) along both long edges.
