About the IS200EMCSG1AAB
The IS200EMCSG1AAB is a component for the Mark VI series. The Mark VI is part of the Speedtronic line of gas/steam turbine management systems developed by General Electric. The Speedtronic line has been used for turbine management since the first Mark I system was released in the late 1960s. The Mark VI includes Ethernet communications, a PC-based operator interface, and pre-loaded software that has been specifically designed for turbine control. The Mark VI Series that this IS200EMCSG1AAB printed circuit board is a component member of has to be considered something of a massive functional upgrade upon the Mark V Series of the same full extended series name that immediately preceded it, as the Mark VI Series introduced the alternative energy-based wind turbine functional application, adding upon the Mark V Series' established gas and steam turbine possible applications. This Mark VI Series is also valued for its status as one of the final-developed GE Mark product series to incorporate the patented Speedtronic control system technology into its various PCB product offerings.
Hardware Tips and Specifications
The IS200EMCSG1AAB is a small board with few components. It functions as a Conduction Sensor and has four conduction sensors built into the front half of the board. These components are labeled E1 to E4. The board has been drilled in two corners (bottom left and top right.) The board is marked with several codes and pieces of information, including the board ID number, the manufacturer’s logo, and the codes CCTC, 94V0, E99006, 0211, and Type5. Other components on the board include two sensor circuits (U1 and U2,) and two power supplies. These power supplies are 2 by 3 plugs. The board also includes a single ceramic capacitor and four metal film resistors. Our team takes great care in packing your order for transit to your facility. Every item purchased from AX Control is automatically warrantied and is guaranteed to not be DOA. Your invoice or quote will have your specific product warranty information, or you can find our current warranty information on our webpage. All warranties are through AX Control and not through the manufacturer. If you have any questions, your sales representative will be happy to help.
All of the IS200EMCSG1AAB Exciter Multibridge Conduction Sensor Card-specific hardware component and component specification information stored above on this IS200EMCSG1AAB personalized product page is actually reminiscent of a singular diligent visual inspection of the IS200EMCSG1AAB printed circuit board itself, which was deemed necessary given the low amount of IS200EMCSG1AAB-pertinent instructional manual materials available online due to frequent copyright infringements upon the Mark VI Series. With this being true, this IS200EMCSG1AAB Conduction Sensor Board does benefit from its General Electric original manufacture in some ways, as it possess the IS200EMCSG1AAB functional product number specially designed to illustrate a number of IS200EMCSG1AAB PCB hardware insights through a series of consecutive functional naming components. For example, this IS200EMCSG1AAB product number in specific begins through an iteration of the dual-responsible IS200EMCSG1AAB functional product number indirectly delegating this IS200EMCSG1AAB PCB's normal Mark VI Series assembly version as well as its domestic original manufacture location. Some of the other relevant IS200EMCSG1AAB board hardware details shared in this fashion include its EMCS functional product abbreviation, its normal PCB coating style, its group one Mark VI Series product grouping, and finally its unique three-fold product revision history.
