About the IS200ERBPG1ACA
The IS200ERBPG1ACA was a product manufactured by GE distributed as a part of the Mark VI series. As a vital portion of the Speedtronic system, the Mark VI was developed throughout the 1990s as a regulator for gas and steam-powered turbines. The Mark VI Turbine Control System Series that this IS200ERBPG1ACA Exciter Backplane Board device belongs to, as should have been indicated above, is something of a self-described GE Mark product series, as it exists with a set of possible functional environments particularly in the control and management systems of popular and General Electric-compatible gas, steam, and wind turbine automated drive assemblies. This is actually a significant functional upgrade upon the previously-released industry standard of the Mark V Turbine Control System Series possessing more or less the same full extended product series title, as the Mark VI Series added the more alternative energy-friendly wind turbine possible functional application onto the earlier-established gas and steam turbine-based options.
Hardware Tips and Specifications
The IS200ERBPG1ACA was constructed to be part of a Central Control Module (13- or 21- slot VME card rack,) which connected on termination boards including a box-type or barrier terminal blocks. Users could access data drawn from the controlling module which made use of an interrelated operator junction (HMI) loaded with cohesive software intended for superior turbine supervision, such as GE’s CIMPLICITY graphics platform. The IS200ERBPG1ACA was an ERBP (Exciter Regulator Backplane.) It typically was used in GE’s EX2100 Control System, which was a third-generation digital excitation scheme. This system was intended to assimilate with the Mark VI and its HMI deprived of any issues. It could also fit in with a stand-alone retrofit application using an Ethernet Modbus or serial communication protocol. This IS200ERBPG1ACA Exciter Backplane Board printed circuit board product offering or just PCB for short is actually not General Electric's originally-developed device of its specific GE Mark VI Turbine Control System Series functionality; that would have to be deemed the IS200ERBPG1 parent Exciter Backplane Board notably not taking advantage of this IS200ERBPG1ACA Exciter Backplane Board device's three-fold extended revision table.
The IS200ERBPG1ACS was created to have a large outward rectangular case. This was open on one side to allow for the insertion of various components and cards. Other areas on the card were perforated to allow for easy airflow. A few of the edges on the casing were fitted with flanges which had small industrial holes drilled through them allowing for easy mounting. The module had a small airflow fan installed toward the rear surface. The ERBP provided communication amongst all the boards mounted within it. These included boards such as IGBT, EPSM, ERDD, ERIO, ACLA, and DSPX. For a comprehensive list of circuit boards connected within the product including ones mounted by means of cable connectors, please look for GE manual GEI-100488a. This IS200ERBPG1ACA Exciter Backplane Board device's originally-printed instructional manual is unfortunately largely unavailable online, which means that this IS200ERBPG1ACA Exciter Backplane Board personalized product page here tends to the rely on the IS200ERBPG1ACA Exciter Backplane Board functional product number in large part. The IS200ERBPG1ACA Exciter Backplane Board functional product number codes for a number of critical IS200ERBPG1ACA Exciter Backplane Board details through a series of consecutive functional naming chunks.Some of these qualities include this IS200ERBPG1ACA Exciter Backplane Board's:
- Normal PCB assembly version
- Domestic manufacture location
- Group one Mark VI Series product grouping
- Three-fold product revision table
