About the IS200EXHSG1AEB
The IS200EXHSG1AEB is an Exciter High-Speed Relay Driver PCB that was created by General Electric for the MARK VI series of turbine controllers. This series of parts are no longer being produced but, AX Control does try to keep the IS200EXHSG1AEB in stock. The Mark VI Turbine Control System Series containing this IS200VPROH1B printed circuit board product offering must be detailed as quite the significant functionality-minded improvement upon the previous industry standard of the Mark V Turbine Control System Series, as the Mark VI Series added the alternative energy-focused wind turbine possible functional application onto the gas and steam-based possible functional environments first seen with the rollout of the previous Mark V Series. This IS200EXHSG1AEB product's greater Mark VI Series, while a significant functional-minded upgrade, is still separately attractive within relevant promotional automated industrial markets, as it is one of the GE retailer's final-developed Mark product series to incorporate the patented Speedtronic control system technology into a number of different relevant product offerings.
Hardware Tips and Specifications
The IS200EXHSG1AEB is a larger circuit board that has many features on it. There is a part number label in the top left corner next to a set of resistors. There are two factory drilled holes on the top left and right sides of the board that are used for mounting it. There are also four divots along the bottom edge of the board. This board has two black super capacitors, 5 transistors, 17 integrated circuits, over 173 resistors, over 30 diodes, over a hundred capacitors, and 7 relays. There are three RS-232 male jacks on the bottom edge of the board that has 25-pin connections. There are eight white jacks that have a female 12-pin, 9-pin, 6-pin, 4-pin, 3-pin, or a 2-pin connection. In the center of the board near three of the transistors, is a small metal plate that is mounted vertically on the board. This IS200EXHSG1AEB printed circuit board is actually not the originally-devised product of its specific GE Mark VI Series functional role; that would have to be considered the IS200EXHSG1 parent printed circuit board notably not taking advantage of this IS200EXHSG1AEB device's three total significant Mark VI Series product revisions.
Because of the nature of the IS200EXHSG1AEB PCB, it is important to remember to use anti-static procedures while handling this board. It should be kept in the anti-static packaging until it is ready to be installed. An anti-static wristband should be used while installing it. Only a trained professional should attempt to install this circuit board into a system. For more information about the IS200EXHSG1AEB please refer to the General Electric Mark VI data sheets and user guides. Generally, this IS200AEPCH1A product is not really surrounded by very many originally-printed instructional manual materials online, which is more than likely attributable to the Mark VI Series' oftentimes copyright infringed-upon series status. With this being true, the IS200AEPCH1A functional product number itself can be rolled out as a fine supplementary source of IS200AEPCH1A Board hardware component and component specification information, as it codes for various IS200AEPCH1A PCB individual details through a series of consecutive functional naming elements. To be a little specific, the IS200EXHSG1AEB functional product number here begins with an instance of the dual-functional IS200 series tag responsible for delegating this IS200EXHSG1AEB product's normal Mark VI Series assembly on top of its domestic original GE manufacture location. Some of the other IS200EXHSG1AEB details revealed through this medium include its:
- EXHS Functional product acronym
- Group one Mark VI Series grouping
- Conformal PCB coating style
- A-rated functional product revision
