About the IS200EXHSG4AEC
This IS200EXHSG4AEC printed circuit board product offering from General Electric, as should have been mentioned just above in the brief IS200EXHSG4AEC product description paragraph, was originally designed and manufactured by the trusted automated industrial giant player GE for their respected and recently-supplanted Mark VI Turbine Control System Series. The Mark VI Series that this IS200EXHSG4AEC device belongs to, as it is known in short, exists with a specific series of possible functional product environments specifically in the management and control systems of popular General Electric-compatible gas, stem, and wind turbine automated drive assemblies. This has to be stated as existing as quite the significant functional upgrade upon the previous industry-standard Mark V Turbine Control System Series of just about the same full extended series title, as the Mark VI Series added the alternative energy-based wind turbine functional product application onto the rudimentary gas and steam turbine-based applications seen with the release of the previous Mark V.
Hardware Tips and Specifications
The IS200EXHSG4AEC is an exciter relay driver board for an EX2100 Excitation System. The abbreviation used by GE for this board and it's family is EXHS. Information regarding the EX2100 migration pattern can be found in the GEZ-S2045 product life cycle documentation. The IS200EXHSG4AEC is a Static Exciter Terminal Board for use in high-speed applications. The EXHS board is built as an identical board to the EXTB board with the exception of the replacement of a solid state relay driver on the EXHS board for the 41 DC contactors on the EXTB board. If you are running high-speed application, please order an EXHS board, as an EXTB will not meet the needs of your system. The IS200EXHSG4AEC is built with seven relays on its surface. Each of these relays carries a reference designator that ends in M1, M2, or C. The board has multiple connectors, including two conduction sensors, three ribbon connectors, and eight (female) plugs of various sizes. The board has one heat sink located near the center of the board. It has integrated circuits and several transistors. Resistors and capacitors are of mixed materials. It is worth noting that some component locations have been marked but hold no component; these are components that vary from board versions and are not needed for this version.
To tell the truth, the entirety of this IS200EXHSG4AEC personalized product page here up to this point has been reminiscent of a diligent visual inspection of the IS200EXHSG4AEC device itself, as inspired by an almost total lack of IS200EXHSG4AEC Board Mark VI Turbine Control System Series originally-printed instructional manual materials on the internet. With this being the case, the IS200EXHSG4AEC functional product number itself can also be introduced as a decent functioning source of IS200EXHSG4AEC Board hardware component and component specification information, as it codes for a number of IS200EXHSG4AEC device qualities through its series of consecutive functional naming elements. For instance, this IS200EXHSG4AEC product number is started off through a standard inclusion of the IS200 series grouping tag that is dually-responsible for delegating both this IS200EXHSG4AEC device's normal Mark VI Turbine Control System Series assembly on top of its domestic original location of GE manufacture. Some of the other hardware details revealed through this GE-produced medium include this IS200EXHSG4AEC product's:
- EXHS functional abbreviation
- Normal PCB coating style
- Group 4 Mark VI Series grouping
- Three-fold revision table
