About the IS200EXMDG1APR
The IS200EXMDG1APR from General Electric functions as an MD interface card. It is used within the Mark VI Speedtronic turbine control system. This was one of the last and most advanced of several turbine control systems for industrial steam turbines released by General Electric under the Speedtronic umbrella. This IS200EXMDG1APR product's Mark VI Turbine Control System Series, as it is known at length, is actually quite the stark functional improvement upon the Mark V Turbine Control System Series of just about the exact same full extended GE Mark product series title, as the Mark VI Series added the alternative energy-based wind turbine functional application onto the gas and steam-based applications seen earlier on with this IS200EXMDG1APR product's Mark V Series previously. This IS200EXMDG1APR device's Mark VI Series is also held in high esteem as one of the final-released GE Mark product series to utilize the patented Speedtronic control system technology first seen with the rollout of the Mark I Series way back in 1969.
Hardware Tips and Specifications
The IS200EXMDG1APR is a small board designed to mount easily using the factory drilled holes located at each corner of the board. The board itself carries several codes along its edges, including wiring and ID codes. There is also a barcode located at one edge that will provide additional information. The board also has the GE logo printed within the body of the board to ensure its authenticity. The IS200EXMDG1APR includes multiple connectors on its surface. This includes two vertical pin connectors that are located parallel to each other. Close to these connectors, there are two additional Augat connectors. One of these is a 3 by 3 connector. The other is a 2 by 3 connector. Finally, there is a right-angled connector with two female connection points and two male pins located along one board edge. Other board components include a relay, a single resistor, and two MOVs (metal oxide varistors). Refer to manuals, datasheets, or user guides from General Electric for additional information. The EX2100 manual may be of some help as this part can be used with that Excitation Control subsystem of the Mark VI. If you need additional copies of these instructions due to loss or misplacement, please let our staff know when you are placing your order.
This IS200EXMDG1APR printed circuit board product offering or PCB for short from General Electric is actually not followed online by very many originally-produced instructional manual materials online, as its greater Mark VI Turbine Control System Series is considered a legacy product series that was discontinued for active production in one of the many years following its original General Electric Mark product series rollout. With this being the case, this IS200EXMDG1APR Interface Circuit Board's IS200EXMDG1APR functional product number itself can be rolled out as a decent to strong primary source of IS200EXMDG1APR Board hardware component and component specification information, as it codes for a number of relevant IS200EXMDG1APR Board hardware details through its series of consecutive functional naming elements. For instance, the IS200EXMDG1APR functional product number begins with an iteration of the dual-functional IS200 series tag delegated to identify this IS200EXMDG1APR device's normal Mark VI Series assembly version as well as its domestic original location of GE manufacture. This IS200EXMDG1APR device's IS200EXMDG1APR functional product number's other applications are detailed in the IS200EXMDG1APR Part Number Breakdown inserted in the IS200EXMDG1APR functional product number, which include the:
- EXMD functional product acronym
- Group one Mark VI Series grouping
- Three-fold revision table
- Normal PCB coating style
