About the IS200GFOIH1A
The IS200GFOIH1A is a Mark VI GE turbine control board. This system from General Electric was one of the most successful gas/steam turbine management systems of the last decades and was part of the Speedtronic series that has been managing turbine systems since the late 1960s. The Mark VI Turbine Control System Series that this IS200GFOIH1A Power Supply Card printed circuit board product offering belongs to in specific, as determined partially through its full extended series name, has a set of possible applications in the management systems and control systems of General Electric-compatible wind, gas and steam turbine automated drive assemblies; a major upgrade upon the Mark V Turbine Control System Series of the same name that preceded it given the Mark V Series' more restricted gas and steam-limited possible functional applications. With this being true. the Mark VI Series that this IS200GFOIH1A product in specific belongs to is separately seen as an important GE Mark product series given its status as one of the trusted company's final-released Mark product series to incorporate the patented Speedtronic control system technology into a number of its different offerings.
Hardware Tips and Specifications
The IS200GFOIH1A board is built with a single backplane connector, designated as P1. This backplane connects the board into the rack system and allows the PCB to communicate with other units within the system. The board also has a vertical pin connector designated as P6 that offers the chance for users to add an optional daughterboard. This board will expand the capabilities of the GFOI board. When the daughterboard is installed it will be held securely by four screw mounts threaded into standoffs located on the motherboard. The IS200GFOIH1A is populated by a number of ICs (integrated circuits) including a Xilinx Spartan XC2S50E chip that functions as an FPGA, or a field-programmable gate array. The board also includes a switch component, four transistors, 9 TP test points, and a number of resistors, diodes, and capacitors. The IS200GFOIH1A board has been factory drilled at each corner to allow for mounting options; each one of these factory-drilled holes have been ringed with a specialized integrated material in observance of potentially present and damaging IS200GFOIH1A Board surface voltages.
Please refer to your original documentation for additional important information about this board, including pertinent information regarding proper handling and installation techniques. This includes manuals, user guides, or datasheets you received with your original order from the OEM. If these items have been lost or misplaced, AX Control may be able to provide access to duplicate copies. Please talk to your sales rep when placing your order. Generally, any of the resistors, capacitors, diodes, or even specialized integrated circuits important to the normal Mark VI Series assembly of this IS200GFOIH1A printed circuit board product offering were only included in this IS200GFOIH1A device's normal Mark VI Series assembly version as part of a greater series-standardized selection of hardware components intended specifically to play a role in voltage suppression and regulation processes. This IS200GFOIH1A printed circuit board or PCB for short needs to access its IS200GFOIH1A functional product number as a primary source of hardware information, given this IS200GFOIH1A device's functional absence of any pertinent instructional manual materials online for the purposes of this IS200GFOIH1A personalized product page here. The IS200GFOIH1A functional product number, for example, begins with the dual-functional IS200 series tag indirectly identifying this IS200GFOIH1A product's normal Mark VI Series assembly version on top of its domestic original manufacture location. Some of the other details revealed in this product number include the IS200GFOIH1A PCB's:
- GFOI functional product acronym
- Group one Mark VI Series product grouping
- Conformal PCB coating style
- A-rated functional product revision
