About the IS200GFOIH1ABA
The IS200GFOIH1ABA is a board component created by GE as a part for the Mark VI system. This system is one of the last of the Speedtronic management platforms with more than thirty years of successful operation and design. It is a complete protection/monitoring/control platform for gas and steam turbines of various size and complexity, and can also be used to integrate power island and balance of plant controls. Hardware and software have been designed to integrate together seamlessly, including software like the CIMPLICITY graphics platform. This IS200GFOIH1ABA Ground Fiber Optic Board's Mark VI Turbine Control System Series represents a massive functional upgrade upon previously-released GE Mark product series such as the Mark IV Series, as the Mark VI Series' possible functional applications range has been expanded to include potential alternative energy-based wind turbine automated drive assemblies. With this being true, this IS200GFOIH1ABA printed circuit board or PCB for short's greater Mark VI Turbine Control System Series is still seen as a separately-attractive GE Mark product series as it is one of the final-developed Mark product series utilizing the patented Speedtronic control system technology across a wide range of its different devices.
Hardware Tips and Specifications
The IS200GFOIH1ABA printed circuit board or PCB for short featured on this IS200GFOIH1ABA personalized product page here has a single backplane connector (P1.) The board also includes a vertical pin connector (P6) and a connector that is designed to accept an optional daughterboard. When installed, the daughterboard is held in place by four screws threaded into standoffs. The daughterboard adds many more components including connectors, tests points, transistors, and integrated circuits; most of these listed components are actually part of a greater voltage limitation strategy standardized to the rest of this IS200GFOIH1ABA product's Mark VI Turbine Control System Series. The IS200GFOIH1ABA is populated by various components including integrated circuits. This includes read-only chips and field programmable gate arrays (Xilinx Spartan XC2S50E.) The board has nine TP test points, a single switch component, four transistors, and many capacitors and resistors. The board is drilled in all four corners for mounting options and has codes on its surface like 6BA00 and 94V-0. The board has coil inductors located in several locations on the board, typically in pairs.More information on the IS200GFOIH1ABA and its components and function can be found through user guides and manuals from General Electric.
Please follow all handling procedures as recommended by the original manufacturer. Any of the above-listed hardware components in the normal Mark VI Series assembly of this IS200GFOIH1ABA Ground Fiber Optic Board have been identified solely through use of a diligent visual inspection of the IS200GFOIH1ABA product itself. This was deemed as necessary given the fact that this IS200GFOIH1ABA device's Mark IV Turbine Control System Series is a GE legacy product series as identified above, and as such, is not followed onto the internet by any great amount of originally-pertinent instructional manual materials. As this is the case, the IS200GFOIH1ABA functional product number itself can be isolated as a decently-strong primary source of IS200GFOIH1ABA Board hardware component and component specification information; coding for various hardware details through a series of consecutive functional naming elements. For example, this IS200GFOIH1ABA product number specifically was begun with an instance of the dual-functioning IS200 series tag delegating this IS200GFOIH1ABA product's normal Mark VI Turbine Control System Series assembly version on top of its more standardized domestic location of original General Electric manufacture. Some of the other relevant hardware details in the IS200GFOIH1ABA functional product number include this IS200GFOIH1ABA device's:
- GFOI functional product acronym
- Group one Mark VI Series product grouping
- Conformal PCB coating style
- Three-fold revision table
