About the IS200GFOIH1B
The IS200GFOIH1B is described as a Ground Fiber Optic Board. This model was made by General Electric as part of the Mark VI IS200 Turbine Control System series and can be used in systems related to the Mark VI IS200 series. The Mark VI Series that this IS200GFOIH1B product offering belongs to is relatively self-described in terms of its specific intended possible applications, given the fact that it exists with specific applications in the management and control systems of General Electric-compatible wind, steam, and gas turbine automated drive assemblies. With this being the case, this IS200GFOIH1B device's greater Mark VI Turbine Control System Series is not surrounded by any great depth of originally-instructional manual materials online; most likely a symptom of the concerted copyright striking efforts employed by GE in the many years past the Mark VI Series' initial product series rollout.
Hardware Tips and Specifications
The IS200GFOIH1B includes a field programmable gate array chip from Xilinx (Spartan XC2S50E.) This chip has a flexible, regular, programmable architecture of CLBs (configurable logic blocks.) It amount of RAM available on this model is 32K. There are four transformers, located in a single line toward the front edge of the board, which also includes nine test points and one pushbutton switch component placed in the front quadrant of the board. The board has several resistor network arrays, along with resistors, capacitors, and diodes. The IS200GFOIH1B has a single backplane connector as well as a small vertical pin connector (P6.) The board also has a connector to accept an optional auxiliary board. When this board is installed, four screw connections threaded through factory-made screw mounts on both boards keep it in place. This IS200GFOIH1B device specifically, while functionally definable in its own right as a Ground Fiber Optic Board, is not the originally-designed product of this specific Mark Series functionality; as that would have to be the IS200GFOIH1 parent Ground Fiber Optic Board not making use of this IS200GFOIH1B product's sole B-rated functional product revision.
More information on the IS200GFOIH1B, its function, installation, components, auxiliary board, and handling instructions can be found through resource publications made available by the manufacturer, such as user guides, data sheets, and manuals. Unfortunately, information on the GFOI model is limited and difficult to find since General Electric has discontinued the model; all of the above information was taken from a visual inspection of the unit. Given the fact that this IS200GFOIH1B product belongs to a General Electric Mark product series whose originally-produced performance specifications and dimensions have not made available online in the form of originally-printed instructional manual materials, this IS200GFOIH1B device's functional product number itself may be identified as a decently-strong source of IS200GFOIH1B Board hardware component and component specification information, as it codes for these various details through a series of functional consecutive naming components. For instance, this IS200GFOIH1B functional product number in particular begins through the dual-functioning IS200 series tag indirectly identifying this IS200GFOIH1B product's normal Mark VI Series assembly as well as its domestic original manufacture location. Some of the other IS200GFOIH1B details made evident through the IS200GFOIH1B functional product number includes its:
- GFOI functional product abbreviation
- Conformal PCB coating style
- Group one Mark VI Series product grouping
- B-rated functional product revision
