About the IS200HSLAH2ADE
The IS200HSLAH2ADE is a printed circuit board component fabricated for the Mark VI Turbine Control System series. The MKVI was one of the final systems distributed by General Electric within the Speedtronic series for the management of heavy-duty gas/steam turbine systems. The MKVI is a complete platform for the protection, control, and monitoring of these types of turbine systems, as you have more than likely been able to decipher based off of its full extended series name alone. The MKVI was designed by GE as a modular, adaptable and scalable system that can have modules added or removed to serve the needs of the corresponding turbine. The Mark VI Turbine Control System Series containing this IS200HSLAH2ADE product is able to attract a consistent draw within the greater automated industrial community promotional marketplace solely given its nature as one of General Electric's final-developed Mark product series to make use of the patented Speedtronic control system technology across a broad range of its different products.
Hardware Tips and Specifications
The IS200HSLAH2ADE is an HS SLR LNK interface board. The board is populated on the top and the bottom board surfaces. This is a small board with a jack connector on its top surface. It has two transformers (Halo TG 110-EO 50N5) along with six inductor coils, several transistors, and many resistors, capacitors, and diodes. The board has over twenty integrated circuits that include a Field Programmable Gate Array at U1. The bottom surface has additional connectors, resistors, transistors, and capacitors; these are but a small part of a greater insulation and voltage protection strategy involving an elevated number of Mark VI Series-standardized voltage-limiting hardware components and component specifications. The IS200HSLAH2ADE is drilled for mounting. Most components are marked with reference designators for ease of identification. Use technical support products like data sheets and product manuals for more information. Your purchase from AX Control includes an automatic, comprehensive warranty at no extra cost to you. Speak to our team for additional information. Our team is available via email or phone and will be happy to answer your questions about our warranty service or any other part of our business.
Given the fact that this IS200HSLAH2ADE product's normal Mark VI Series printed circuit board assembly version makes use of no attached front faceplate, this IS200HSLAH2ADE product can be assumed not to mount in the Mark VI Series' typical VME Rack Installation Assembly. The IS200HSLAH2ADE functional product number can be described as a decent primary source of IS200HSLAH2ADE Board hardware component and component specification information, given this IS200HSLAH2ADE product's lack of original instructional manual materials available for this IS200HSLAH2ADE personalized product page available online; likely a symptom of this IS200HSLAH2ADE device's previous manufacturing discontinuation from General Electric. The IS200HSLAH2ADE functional product number begins with a dual-functional IS200 series tag, and delegates a number of important hardware details through a series of consecutively-developed functional naming components. The beginning dual-functional tag starting off the IS200HSLAH2ADE functional product number is telling of both this IS200HSLAH2ADE Serial Link Interface Board's normal Mark VI Series assembly as well as its domestically-manufactured product status. Some of the other relevant details embedded in this IS200HSLAH2ADE functional number include the IS200HSLAH2ADE product's:
- HSLA functional product abbreviation
- Conformal PCB coating style
- Group 2 Mark VI Series product grouping
- Three-fold revision table
