IS200ICCAH1ADB

About the IS200ICCAH1ADB

The IS200ICCAH1ADB is a Mark VI PCB component manufactured by GE.  The MKVI was one of the last of the Speedtronic systems released by General Electric for the management of gas and steam turbines.  The MKVI is built with a central Control Module that connects to the rest of the system via multiple termination boards equipped with a TMS320C32 DSP processor to digitally filter data.   Most data from the system can be accessed through a connected HMI (operator interface) run through a Windows-based PC. Since control actually occurs within the Control Module, the HMI can be replaced, restarted, or updated with no impact to the turbine system.

The IS200ICCAH1ADB is designed to function as an Innovation Drive Control board.  It has a narrow front faceplate connected to the PCB via three connection points. The PCB has two backplane connectors placed along its rear edge that are labeled P1 and P2.  The board is built with several other connectors that are labeled P3, P4, P5, P6, and P7. The majority of these are composed of conductive dots enclosed by a border.

The board is built with a CPU socket and over thirty-five other integrated circuits.  It has over 150 capacitors and the same number of resistors. The board has ten test points and multiple transistors.  The board has three black square components that attach to the board using short standoffs and pegs.
