About the IS200ICIAH1ABB
The IS200ICIAH1ABB is a Printed Circuit Board produced by General Electric for the Innovation Series. This board is no longer being supported by GE and may be a little hard to find now. AX Control does try to keep the IS200ICIAH1ABB in stock as a refurbished or new surplus board. The Mark VI Turbine Control System Series containing this IS200ICIAH1ABB Printed Circuit Board device is quite the noticeable functional upgrade upon the previous industry-standard Mark V Turbine Control System Series of just about the exact same full extended series title, as the Mark VI Series added the alternative energy-based wind turbine possible application onto the rudimentary gas and steam turbine-based applications seen with the Mark V Series' rollout.
Hardware Tips and Specifications
The IS200ICIAH1ABB is a replacement PCB attached to a faceplate. There isn’t anything on the faceplate of this card except two brackets and mounting screws. This board is meant to be plugged into the backplane of a card rack assembly. It plugs into a specific slot on in the rack. Failure to plug it into the right slot could damage the board or the card slot. On the IS200ICIAH1ABB there are at least 120 resistors, 80 capacitors, 7 red metal oxide varistors, at least 40 integrated circuits, two jumpers, 2 stab-on connectors, 7 relays, three fuses, and many diodes. There is a connector that plugs into a card slot on a backplane. There are also three white 24-pin, 16-pin, and 20-pin connectors. For more information about the IS200ICIAH1ABB, please refer back to the original GE datasheets, user guides, and instruction manuals for the Innovation Series. Only a trained professional should attempt to install this board. Because of the nature of this product, it is advisable to maintain proper anti-static procedures while handling this card. AX Control offers many different air and ground shipping options for the IS200ICIAH1ABB. Please contact us directly for the availability, pricing, and shipping quotes for this card. Generally, any fuse, diode, rectifier, and capacitor in this IS200ICIAH1ABB Printed Circuit Board device's assembly is part of a broader series-standardized selection.
This IS200ICIAH1ABB Printed Circuit Board product's above-attached hardware component and component specification information is only telling of a diligent visual inspection of the IS200ICIAH1ABB Printed Circuit Board device itself, as guided by one of our diligent and experienced lead service technicians. This is due to the IS200ICIAH1ABB Printed Circuit Board device's greater Mark VI Turbine Control System Series' legacy product series attribution. With this being the case, the IS200ICIAH1ABB Printed Circuit Board functional product number itself can also be rolled out as a fine original supplementary source of IS200ICIAH1ABB Printed Circuit Board hardware component and component specification information, as it codes for a number of relevant IS200ICIAH1ABB Printed Circuit Board hardware qualities through a series of consecutive functional naming elements. For instance, this IS200ICIAH1ABB Printed Circuit Board device's IS200ICIAH1ABB Printed Circuit Board functional product number begins with an iteration of the dual-functional IS200 series tag that demonstrates both this IS200ICIAH1ABB Printed Circuit Board PCB's normal Mark VI Series assembly as well as its domestic original GE manufacture location. Some of the other important IS200ICIAH1ABB Printed Circuit Board device information indicated through this medium includes its:
- ICIA functional product abbreviation
- Conformal PCB coating style
- Group one Mark VI Series product grouping
- Three-fold extended revision table
