About the IS200ISBEH2A
The IS200ISBEH2A is a component manufactured by General Electric for the Mark VI system. One of the last Speedtronic gas/steam turbine management systems, the MKVI is considered a complete solution for the protection, control, and monitoring needed for a heavy-duty turbine, including all the hardware and software. The MKVI is built with an HMI (operator interface) that is based on a PC running a Microsoft Windows platform and preloaded with CIMPLICITY graphics display as well as other proprietary software. The HMI connects directly to the central Control Module, where all the control and protection for the system occurs. This allows the HMI to be replaced or reinitialized with no impact to running processes. This IS200ISBEH2A Insync Bus Extender Module device can be repaired or replaced today.
Hardware Tips and Specifications
The IS200ISBEH2A is an ISbus Extender board that functions as a transmit/receive connector usually designed to mate directly with the J11A local ISBus Interface Connector on the Control Assembly Backplane (IS200CABP.) The board has a DATEL DC/DC converter with 18V to 36V input, 5V output @ 1A. The board has several connectors, including two plugs marked P1A and P1B. There are two terminal strips with two positions each, located at opposite sides of the board, and two fiber-optic connectors (R and T.) The board has four conduction sensors (E1 through E4.) The board has one three position jumper switch. The board has an information box labeled “JP1-Interlock Bypass” with the following information: 1-2 Unbypassed, 2-3 Bypassed. The board has three LEDs and eight integrated circuits. The board also has resistors, diodes, and capacitors. This IS200ISBEH2A Insync Bus Extender Module product offering is actually not the originally-developed Mark VI Series product of its specific functionality; that would be the IS200ISBEH2 Insync Bus Extender Module parent PCB product not utilizing this IS200ISBEH2A Insync Bus Extender Module device's A-rated revision.
Refer to manuals or datasheets referencing the IS200ISBEH2A part number for guidelines on installation. Unfortunately, while many of these manuals have been made available with your original purchase from General Electric, they are generally not available online, and therefore cannot be accessed for the sake of this IS200ISBEH2A Insync Bus Extender Module personalized product page here. With this being the case, this IS200ISBEH2A Insync Bus Extender Module device's IS200ISBEH2A Insync Bus Extender Module functional product number itself stands to serve as a fine source of IS200ISBEH2A Insync Bus Extender Module hardware component and component specification detail, as it was specially designed by GE to illustrate a number of significant IS200ISBEH2A Insync Bus Extender Module details through its standard series of consecutively-arranged functional naming elements. For instance, this IS200ISBEH2A Insync Bus Extender Module device's normal Mark VI Turbine Control System Series assembly version as well as its domestic original location of GE manufacture was made obvious upon the insertion of the initial IS200 chunk known as the IS200 series tag. Some other important IS200ISBEH2A Insync Bus Extender Module specific qualities indicated to us in this manner include the IS200ISBEH2A Insync Bus Extender Module's:
- ISBE functional product abbreviation
- Conformal PCB coating style
- Group 2 Mark VI Series product grouping
- A-rated functional product revision
