About the IS200ISBEH2ABC
The IS200ISBEH2ABC is a PCB component made by GE for the Mark VI system. The MKVI was one of the last of the Speedtronic gas or steam turbine management series released by General Electric. Turbine management systems developed and released under the Speedtronic name were considered some of the most reliable turbine systems on the market for several decades. The Mark VI includes Ethernet communications and an Operator Interface (HMI) that consists of a PC with a Windows operating system. The HMI allows users to access data within the system but is a non-essential part of the system. This IS200ISBEH2ABC InSync Bus Extender Card device's greater Mark VI Turbine Control System Series is generally held in high esteem as one of the lastly-developed GE Mark Series iterations to make use of their patented Speedtronic control system technology across a wide variety of functional product offerings.
Hardware Tips and Specifications
The IS200ISBEH2ABC is an InSync Bus Extender Card. This board has multiple connectors of various types, including two male plug connectors on the right edge, two fiber-optic connectors on the left edge of the board, two terminal strips with two positions on each strip, and four round conduction sensors, one placed near each corner. The board also has a DATEL DC/DC converter that is rated for 18 V to 36 V input and a 5 V output at 1 Amp. The IS200ISBEH2ABC has one jumper switch. This is a three-position switch that functions as an interlock bypass. When the jumper is placed at 1-2 it is set in an unbypassed position. At 2-3, it is in a bypassed position. This information is printed on the board surface. The board is built with three light emitting diodes (LEDs,) various capacitors and resistors, and eight integrated circuits. AX Control offers shipping services around the world. We service all countries not currently affected by US Embargo. A shipping quote will happily be provided upon request. Any diode, resistor, capacitor, or even specialized integrated circuit in the normal Mark VI Series assembly of this IS200ISBEH2ABC device here has been provided as part of a standardized selection of voltage-limiting hardware components made available to the majority of the rest of the Mark VI Turbine Control System Series PCB products.
The entirety of the above attached IS200ISBEH2ABC Board-specific hardware component and component specification information has been derived from information revealed upon a diligent service technician-led visual inspection of the IS200ISBEH2ABC PCB itself paired with any information available upon synthesis of this IS200ISBEH2ABC product's more general Mark VI Turbine Control System Series instructional manual materials. Given the low general online availability of this IS200ISBEH2ABC InSync Bus Extender Card product's specific original instructional manual materials, the IS200ISBEH2ABC functional product number itself can be rolled out as a decent supplemental option for IS200ISBEH2ABC InSync Bus Extender Card hardware component and component specification detail identification, given that it was specifically designed by General Electric to illustrate a number of important IS200ISBEH2ABC InSync Bus Extender Card hardware qualities through a series of consecutive functioning naming chunks. For example, this IS200ISBEH2ABC InSync Bus Extender Card product number starts off through an inclusion of the typical IS200 series tag, which is dual-functional as it identified both this IS200ISBEH2ABC InSync Bus Extender Card product's normal Mark VI Series assembly as well as its domestic original GE manufacture location. Some of the other important IS200ISBEH2ABC InSync Bus Extender Card device qualities indicated through this medium include its:
- ISBE functional product acronym
- Conformal PCB coating style
- Group 2 Mark VI Series grouping
- Three-fold revision table
