About the IS200ISRJG1AAA
The IS200ISRJG1AAA is a General Electric RJ45 Adapter (ISRJ) created for the Innovation Series. This series of parts are no longer being supported by GE and they have become a little hard to find. AX Control does still try to keep the IS200ISRJG1AAA in stock. The Innovation Series that this IS200ISRJG1AAA device can be attributed as a component member to is actually a significant component subseries of the greater Mark VI Turbine Control System Series. This IS200ISRJG1AAA product's true Mark VI Series, as you can probably tell based off of its full extended product series title alone, exists with a specific set of possible functional applications in the management systems and control systems of General Electric-accepting gas, steam, and wind turbines. This can be defined as quite the significant functional enhancement upon the previous industry-standard Mark V Turbine Control System Series of a similar full extended series title, as the Mark Series' functional product range only added on the alternative energy-based wind turbine functional product application with the introduction of the Mark VI.
Hardware Tips and Specifications
The IS200ISRJG1AAA is a PCB that is very small. The board is comprised of only two yellow capacitors, two ethernet jacks, and two terminals. The terminals are labeled E2 and E1. There is a P12 10-pin plug that is in between the two ethernet connectors. There are two factory drilled holes on the bottom right and top left sides of the ISRJ. Placing standoffs into the two holes, this board can be connected to another board. RJ45 connections are 8-pin jacks that can be used to connect devices to a local area network (LAN) that is ethernet-based. More information about the IS200ISRJG1AAA can be found in the datasheets, instruction manuals, and user guides made by GE about Innovation Series PCBs. Only a qualified professional should make the attempt to install the ISRJ. Antistatic procedures should be used when installing and handling this board, based on the type of board it is and the boards it may interact with. To prevent static from being generated and discharged, wear an antistatic wristband. Static shock has the ability to severely damage the delicate circuitry that is generally found on Innovation Series boards.
AX Control may be contacted directly for more information about the pricing, availability, and shipping options available for the IS200ISRJG1AAA.Generally, any of the IS200ISRJG1AAA Board-specific hardware information stored within the bounds of this IS200ISRJG1AAA personalized product page above has been reminiscent of a visual inspection of the IS200ISRJG1AAA product itself, having been lead by a diligent and passionate in-house circuit board service technician. This was deemed as necessary given the relatively low availability of this IS200ISRJG1AAA device's original instructional manual materials online. With this lack being identifiable, the IS200ISRJG1AAA functional product number itself can actually be rolled out as a decent source of IS200ISRJG1AAA Board hardware component and component specification information, as it codes for a series of relevant IS200ISRJG1AAA Board details through a consecutive set of functional naming elements. For example, this IS200ISRJG1AAA product number in particular is started off through its inclusion of the dual-functional IS200 series tag delegating this IS200ISRJG1AAA product's normal Mark VI Series assembly version as well as its domestic original manufacture location. Some of the other relevant IS200ISRJG1AAA Board detail revealed through this medium includes its:
- ISRJ functional product abbreviation
- Normal PCB coating style
- Group one Mark VI Series grouping
- Three-fold revision total
