About the IS200JPDDG1AA
The IS200JPDDG1AA is a GE Mark VI board component. The MKVI system is one of General Electric’s Speedtronic line, which has been used for the management of heavy-duty gas and steam turbines for decades. The Mark VI is built around a central Control Module. This module is responsible for the majority of the control, monitoring, and protection of the system. The Mark VI Turbine Control System Series that this IS200JPDDG1AA DC PDM Module device belongs to, as it is known at length, exists with a specific series of possible functional applications in the control and management system of General Electric-compatible gas, steam, and wind turbine automated drive assemblies; this must be considered significant functionality-minded step up from the existing Mark V Turbine Control System Series of just about the same full extended series title, as the Mark VI Series tacked the alternative energy-based wind turbine possible functional application onto the gas and steam-based functional applications established earlier on through this IS200JPDDG1AA DC PDM Module device's Mark V Turbine Control System Series.
Hardware Tips and Specifications
The IS200JPDDG1AA is a DC power distribution board. This board is a branch circuit board, of which there are several in the Mark VI system, which is used to provide additional distribution of ac/dc power for the output of the core PDM elements. The IS200JPDDG1AA is used with a single input of 125 VDC, 24V, or 48V. The IS200JPDDG1AA is a small rectangular board with few components. It is built with six on/off switches that each correspond to two fuses. The fuses are marked as positive or negative (FU1P/FU1N.) Each on/off switch corresponds to a 2-position plug located on one edge. These plugs are labeled JD1, JD2, JD3, JD4, JD5, and JD6. The board has two more two-position plugs and two more plugs with more positions located on its surface. Each plug is labeled. The surface of the IS200JPDDG1AA includes resistors and diodes, including six LEDs that indicate the power status of outputs. There is a single conduction sensor located in one corner that is marked “TB1.” If your product is marked as being “in stock” we can usually ship it the same day you place your order. We will be happy to provide shipping quotes upon request.
This IS200JPDDG1AA DC PDM Module printed circuit board personalized product page here has thus far been reminiscent of a diligent visual inspection of the IS200JPDDG1AA DC PDM Module device itself, which was necessary given the low general amount of accessible IS200JPDDG1AA DC PDM Module instructional manual documentation available on the internet for this page's research purposes. With this being the case, the IS200JPDDG1AA DC PDM Module functional product number itself can also be rolled out as a decent to strong source of IS200JPDDG1AA DC PDM Module Board hardware component and component specification information, given that it codes for a series of important IS200JPDDG1AA DC PDM Module device characteristics through a standard series of consecutive functional naming elements. For starters, the IS200JPDDG1AA DC PDM Module functional product number starts off with a standard instance of the dual-functional IS200JPDDG1AA DC PDM Module product number dictating this IS200JPDDG1AA DC PDM Module device's normal Mark VI Series assembly on top of its domestic original location of GE manufacture. Some of the other important IS200JPDDG1AA DC PDM Module details revealed in this manner include its:
- JPDD functional product acronym
- Group one Mark VI Series grouping
- Two-fold revision total
- Normal PCB coat of protection
