About the IS200KSPAH1BAA
The IS200KSPAH1BAA model is part of the Mark VI series produced by General Electric and was modeled as an auxiliary daughterboard. The Mark VI Turbine Control System Series that this IS200KSPAH1BAA Signal Processing Auxiliary Card device belongs to, as you can tell through its full extended product series title, exists with a set of possible functional applications specifically in the control and management systems of GE-compatible gas, steam, and wind turbine control systems. This has to be described as quite the functional improvement upon the previously-developed Mark V Turbine Control System Series of just about the same full extended product series title, as the Mark VI Series added the more alternative energy-focused wind turbine possible functional environment onto the more rudimentary gas and steam turbine-based applications seen with the Mark V. This IS200KSPAH1BAA Signal Processing Auxiliary Card device's Mark VI Series is also generally desirable as a function of its status as one of the final-developed GE Mark product series to utilize the relevant Speedtronic control system technology across quite the range of offerings.
Hardware Tips and Specifications
This model is an auxiliary daughterboard for the IS215GFOIH module. When the KSPA model was manufactured, it was modeled as a Signal Processing Auxiliary card. The IS200KSPAH1BAA is typically used as part of an IS215GFOIH module and attaches to the motherboard via four screw connections threaded through factory-made holes rimmed with brass. More information on the motherboard module can be found under its separate listing. While the KSPA model can be attached to the GFOI unit through the four screws, it is difficult to know and understand how the two models will work together within the Mark VI series. For this information, it would be best to contact General Electric directly. This specific IS200KSPAH1BAA Signal Processing Auxiliary Card printed circuit board product offering is actually not the originally-developed device of its specific GE Mark VI Turbine Control System Series intended functional product role; that would have to be the IS200KSPAH1 parent Signal Processing Auxiliary Card notably not taking advantage of this IS200KSPAH1BAA Signal Processing Auxiliary Card device's three-fold revision table.
The IS200KSPAH1BAA has components mounted to its front and back surfaces. The more heavily populated side of the board includes two inductor coils (used as chokes or filters,) two board connectors, two transformers, nine capacitors, seven resistors, and nine integrated circuits. The board has a Digital Signal Processor chip located in the upper left quadrant. It also has two switching regulators and an SDR SDRAM chip. The other side of the board has an additional integrated circuit, a transistor, TP test points, and more resistors and capacitors. The board is marked with codes like ttm4-10, 94v-0, 6BB00, and 6DA00. Unfortunately, this IS200KSPAH1BAA Signal Processing Auxiliary Card device is not made available with very many originally-developed instructional manual materials online, which means that its IS200KSPAH1BAA Signal Processing Auxiliary Card functional product number can be rolled out as a fine original source of IS200KSPAH1BAA Signal Processing Auxiliary Card hardware component and component specification information. For example, this IS200KSPAH1BAA Signal Processing Auxiliary Card functional product number begins with an iteration of the dual-functional IS200 series tag delegating this IS200KSPAH1BAA Signal Processing Auxiliary Card device's normal Mark VI Series assembly on top of its domestic original manufacture location. Some of the other important IS200KSPAH1BAA Signal Processing Auxiliary Card device qualities revealed in this manner include its:
- KSPA functional product acronym
- Group 1 Mark VI Series grouping
- Conformal PCB coating style
- Three-fold revision table
