About the IS200LSGIH1APR
The IS200LSGIH1APR from General Electric is designed to be a replacement component for the company’s Mark VI Speedtronic system. Like other Speedtronic systems that came before it, the Mark VI is designed to control and manage industrial gas and steam turbine systems. Unlike earlier systems, the MKVI offers significant options for personalization to the needs of the end-user depending on the size and complexity of the associated turbine. The Mark VI Turbine Control System Series that contains this IS200LSGIH1APR printed circuit board product offering here also represents a significant upgrade upon the Mark V Turbine Control System Series of the same full extended series name that came before it given the fact that its potential functional applications have been expanded to include the control and management systems of General Electric-compatible wind turbine automated drive assemblies, instead of the more-restricted gas and steam turbine applications alone. This IS200LSGIH1APR product's greater Mark VI Series is additionally seen as a strong GE Mark product series offering given the fact that it is one of the last-developed GE Mark product series to incorporate the patented Speedtronic control system technology into a range of different offerings, with this technology first being seen with the rollout of the Mark I Series in the mid to later 1960s.
Hardware Tips and Specifications
The IS200LSGIH1APR board functions as part of the company’s LS2100e static starter system. This is typically used in conjunction with the Mark VI ICS, EX2100e control, and an HMI. The IS200LSGIH1APR allows for different mounting options via its factory drilled corners. The board can accept and accommodate daughterboards. There are two locations on the board where connectors and standoffs will allow auxiliary boards to be mounted to the surface of the primary board. These are marked off by straight lines on the board’s surface. The IS200LSGIH1APR has several connectors, including four Augat connectors. Three of these connectors are the same size. The remaining connector is significantly smaller than the others. Additionally, the board has three vertical pin connectors lined up side-by-side along one short board edge. Each connector includes retaining clips to ensure the connection is properly maintained.
Other components on the IS200LSGIH1APR include several lines of light-emitting components, diodes, resistors, transistors, and capacitors; most of these listed components play a part in this LS2100E Gating Interface Board product's normal Mark VI Series assembly as series-standardized components catered to voltage regulation and suppression processes specifically. The board itself carries the GE logo and is also marked with codes that will help the end-user with installation. More information about this board can be sourced through original manuals or product guides from General Electric. This IS200LSGIH1APR printed circuit board product offering is not surrounded by many originally-pertinent instructional manual materials online, nor is it readily available here for visual inspection given its generally-low market availability. With this being the case, the IS200LSGIH1APR functional product number alone can be leaned on as a decent-to-strong source of IS200LSGIH1APR Board hardware details; coding for specific informational bits through a characteristic series of functional naming elements. For example, the IS200LSGIH1APR functional product number is started by an instance of the dual-functional IS200 series tag indirectly responsible for dictating this IS200LSGIH1APR product's normal Mark VI Series assembly version on top of its domestic original manufacture location. Some of the other relevant specifications revealed in this manner include this IS200LSGIH1APR PCB's:
- LSGI functional product abbreviation
- Conformal PCB coating style
- Group one Mark VI Series product grouping
- Three-fold revision history
