IS200SFCBG1A

About the IS200SFCBG1A

Greater Product Series Information

General Electric, also known as GE, created the IS200SFCBG1A to be a component in the Mark VI series. This series is one of several in the Mark lineup by GE. The IS200SFCBG1A is a large square printed circuit board or PCB. The greater Mark VI Turbine Control System Series that this IS200SFCBG1A Firing Circuit Board device may be attributed to, as you can probably tell based off of its full series title:

• Is a now-obsolete legacy product series
• Is a turbine-oriented product series
• Extends to wind turbine applications, upgrading the Mark V Series

Hardware Tips and Specifications

The IS200SFCBG1A circuit board contains a variety of electronic components. This SFCB-abbreviated product includes in its normal assembly:

• two (2) terminal blocks which are solid green have been attached to the top border of the PCB. Both terminal blocks contain three (3) terminals for a total of six (6) terminals
• two (2) very large grey resistors have been positioned on the IS200SFCBG1A on the upper half of the circuit board
  • both of these resistors are in a rectangular shape
  • they have each been attached to the IS200SFCBG1A’s surface with silver wires
• a large switch which has been made from silver metal has been attached to the top half of the IS200SFCBG1A
  • connected to the PCB by two (2) wires which are solid white

The full part number of the device, IS200SFCBG1A is marked on the bottom left of the printed circuit card using a series of white letters and numbers. SFC boards such as the IS200SFCBG1A are devices known as single phase relays. These parts feature static time overcurrent units. Also contained on these boards are devices called optional hinged armature-type overcurrent units. These provide tripping which is instantaneous when the current level is high. This overcurrent features high seismic capabilities. Time overcurrent relays protect industrial and utility distribution systems and protect overload backup.
