About the IS200SRTDH1A
This IS200SRTDH1A Simplex Resistance Temperature Device printed circuit board product offering from General Electric, as mentioned just above, was originally designed and manufactured specifically for placement in the Mark VI Turbine Control System Series. The Mark VI Series that this IS200SRTDH1A Simplex Resistance Temperature Device product belongs to, as it is known for short, exists with a set of possible functional applications specifically in the control and management systems of General Electric-compatible gas, steam, and wind turbine automated drive assemblies. This must be defined as quite the significant functional upgrade upon the previously-existing Mark V Turbine Control System Series of the same full extended series name, as the Mark V Series exists with a more restricted set of gas and steam-based functional applications alone.
Hardware Tips and Specifications
Simplex Resistance Temperature Device Input (SRTD) Terminal Board IS200SRTDH1A is part of the Mark VIe series produced by General Electric. This specific board is described as a compact RTD board and will be either flat or DIN-rail mounted. When in the Mark VIe system this board will be used with the PRTD I/O pack. The PRTD will plug into the pin connector of the SRTD, the specific connector is a DC-37 and will communicate with the controllers over an Ethernet connection. This board can only be used within simplex systems, if used in other types of systems errors will occur. Unfortunately enough for the sake of this IS200SRTDH1A Simplex Resistance Temperature Device personalized product page here, this IS200SRTDH1A Simplex Resistance Temperature Device is not accompanied online by any great amount of originally-printed instructional manual materials. With this being the case, the IS200SRTDH1A Simplex Resistance Temperature Device's IS200SRTDH1A functional product number itself can be introduced as a decent functioning source of IS200SRTDH1A Board hardware component and component specification details, as it codes for relevant qualities through a series of consecutive functional naming elements. For instance, that IS200SRTDH1A functional product number begins through an inclusion of the dual-functional IS200 series tag delegating this IS200SRTDH1A product's normal Mark VI Series assembly version on top of its domestic original manufacture location. Some of the other relevant IS200SRTDH1A Board qualities revealed in this fashion include its:
- SRTD functional product abbreviation
- Conformal PCB coating style
- Group one Mark VI Series grouping
- A-rated functional revision
There are two different types of SRTD boards, this board being the IS200SRTDH1A board will have a permanently attached terminal block that will have thirty-six terminals. It is important to note that the RTDs on the board are automatically calibrated; the automatic calibration is done through filtered null voltages and calibration sources. There are several different types of RTDs which are, 120 Ω nickel, 10 Ω copper, and 200, 10, and 100 Ω platinum. When the IS200SRTDH1A terminal board is mounted it needs to be mounted with a plastic insulator when DIN-rail mounted. In some cases, the insulator and SRTD can mount on a sheet metal assembly that will be bolted directly on the chosen cabinet. For more information regarding the IS200SRTDH1A the Mark VIe System Hardware Guide GEH-6721L. While considered mostly obsolete this board can still be found in new and used surplus, if you would like to purchase this board, please contact our sales team Monday through Friday during normal business hours for information regarding pricing and shipping times.
