About the IS200TBAIH1BAA
General Electric Analog Board IS200TBAIH1BAA was designed for the Mark VI Series. The Mark VI Series is a fully programmable control system that can be used in Triple Modular Redundant (TMR) or Simplex applications. The Mark VI Turbine Control System Series, as it is known at its full length, was originally developed by General Electric to encompass a series of functional applications in the control and management systems of General Electric-compatible automated drive assemblies. With this being the case, the Mark VI Series is still very much a desirable GE Mark product series, given the fact that it exists as one of the final-developed GE Mark product series to take advantage of the patented Speedtronic control system technology first seen with the rollout of the initial Mark I Series in the mid to later 1960s.
Hardware Tips and Specifications
This model will be used in applications in which the power supply will be one hundred twenty or two hundred forty volts of alternating current which will then be converter to an isolated one hundred twenty-five volts of direct current. While many of the other boards within the Mark VI Series have some type of LED to indicate what is occurring on the board, the IS200TBAIH1BAA board does not have any of these features. As such this board would have to be used with another board within the Mark VI Series to indicate potential faults and what is occurring on this board. One feature of this board is the potential to perform general-purpose inputs and outputs. Some of the general-purpose inputs and outputs are temperature monitoring, analog I/O, and discrete I/O. This IS200TBAIH1BAA printed circuit board product offering from General Electric is actually not considered the originally-developed device of its specific Mark VI Series functional role; that would have to be considered the IS200TBAIH1 parent Analog Termination Board not making use of this IS200TBAIH1BAA device's three-fold revision history including a B-rated functional product revision, an A-rated functional revision, and an A-rated artwork configuration revision.
Unfortunately, the IS200TBAIH1BAA Analog Board is no longer being actively produced, due to this, the status of the model is considered obsolete but AX Control carries this model in both new and used surplus. For more information, regarding the price and shipping times of this board please reach out to our sales department at (919) 372-8413 or by email at sales@axcontrol.com. This board also comes with a three-year warranty. Please take into consideration that if you would like the board shipped out the same day that you are placing your order, order before 3 p.m. While this IS200TBAIH1BAA Analog Termination Board product is not followed online by any plethora of originally-printed instructional manual materials as referenced above, it is mentioned at least once in the IS200TBAIH1BAA Analog Termination Board instructional manual inserted above for your convenience of research. This IS200TBAIH1BAA instructional manual actually makes reference to a number of IS200TBAIH1BAA Board important hardware specifications, including this IS200TBAIH1BAA product offering's:
- Eight total 4-20ma 250 ohms +/-5,10Vdc inputs
- Two total 4-20ma 250 ohms / +/-1ma 500 ohms inputs
- +24Vdc voltage per each mentioned input
- Two +24V, 0.2A current-limited power supplies
- A sole 500 ohms 4-20ma output
- A singular 500 ohms 4-20ma / 0-200ma output
