About the IS200TBAOH1A
The IS200TBAOH1A is a printed circuit board which can be better contexualized within its functional role as an analog output terminal board. This is a form of printed circuit board or PCB manufactured by General Electric or GE as a component in the Mark VI series. The Mark VI and the other constituent series in the Mark line are used to regulate the processes of gas and steam turbines and have been since the introduction of the Mark I almost fifty (50) years ago. This IS200TBAOH1A product' Mark VI Series represents quite the expanded functionality upon the potential ranges of previously-developed Mark Series iterations such as the Mark IV Turbine Control System Series of the same name, as the Mark VI Series possesses additional functional applications in newer alternative energy-based wind turbine automated drive assemblies. With this being the case, this IS200TBAOH1A product's Mark VI Series is additionally seen as an attractive product series on its greater figurative automated industrial marketplace given its status as one of the final-developed GE Mark product series to incorporate the brand's patented Speedtronic control system technology into a number of its different offerings.
Hardware Tips and Specifications
The IS200TBAOH1A is a printed circuit board or card which is long and slim in size. Two (2) large devices called terminal blocks have been positioned on the left edge of the IS200TBAOH1A. The terminal blocks are green and contain a series of small metal components called terminals. The blocks are named TB1 and TB2. The right half of the IS200TBAOH1A is taken up with six (6) connector ports. These ports each contain a number of small holes called “female” connectors which are used to attach other devices to the IS200TBAOH1A. The connector ports are laid out in vertically in three (3) pairs of two (2) ports each. The bottom part of the right half of the IS200TBAOH1A is occupied by a collection of potentiometers or variable resistors arranged into two (2) vertical rows. Seven (7) potentiometers are lined up in each row. An additional pair of potentiometers has been placed below these two rows. The IS200TBAOH1A has been lined with many small capacitors which are square shaped. Also featured on the IS200TBAOH1A are many very small resistors which feature multicolored bands.
Any capacitor, resistor, diode, transistor, or integrated circuit listed above in the normal assembly of this IS200TBAOH1A Mark VI Series printed circuit board should exist as part of a broader Mark VI Series-standardized of hardware components meant for voltage suppression and limitation purposes specifically. The entirety of this IS200TBAOH1A printed circuit board or PCB for short's previously-listed hardware component and component specification details have been sourced from a visual inspection of the IS200TBAOH1A product itself, which was deemed as necessary given its low amount of online-available original instructional manual materials. With this general lack being identified, the IS200TBAOH1A functional product number itself here can be considered a fine supplementary source of IS200TBAOH1A Board hardware information, as it codes for relevant IS200TBAOH1A Board hardware details in a General Electric-specialized series of functional naming segments or chunks. To demonstrate, the IS200TBAOH1A functional product number here begins with an iteration of the dually-functioning IS200 series tag indirectly delegating this IS200TBAOH1A device's normal Mark VI Series assembly on top of its domestic original manufacture location. Some of the other hardware components revealed through this medium include the IS200TBAOH1A Board's:
- TBAO functional product abbreviation
- Conformal PCB coating style
- Group one Mrk VI Series grouping
- A-rated functional product revision
