IS200TBQDH1AAA

About the IS200TBQDH1AAA

General Electric created the IS200TBQDH1AAA termination module to be a component in the Mark VI series of gas and steam turbine controls. The Mark VI is the latest version of the Mark line, which has been used in turbines across various industries to provide reliable turbine management for decades. The IS200TBQDH1AAA is a type of printed circuit board or PCB.

The IS200TBQDH1AAA is a relatively small circuit board which is long and rectangular in shape. Positioned along the right edge of the IS200TBQDH1AAA are two (2) long green terminal blocks. Each terminal block contains a series of small cube-shaped silver metal components which are known as terminals. The bottom section of the IS200TBQDH1AAA is occupied by three (3) connector ports which are black and contain many “male” connector pins. These connector ports have been arranged parallel to each other. To the right of these connector ports is a series of metal jumper pins. These pins may be connected with black plastic components known as jumpers. Connecting two (2) jumper pins together alters the functions of the PCB. A collection of eight (8) capacitors which are solid red and round can be seen above the connector ports in the center of the IS200TBQDH1AAA. Many more of these capacitors, around twenty-four (24) altogether, have been placed near the top of the IS200TBQDH1AAA on the left half. In the center of the IS200TBQDH1AAA, a series of around twenty (20) small black devices known as diodes have been positioned. These diodes shaped like squares.
