About the IS200TBQGH1A
The IS200TBQGH1A is a General Electric board component typically used when migrating a system from a Mark V Speedtronic system to a Mark VIe Speedtronic system. Both systems, created by GE, have been used for the management of industrial turbine systems. The Mark VIe offers more advanced management control options. The IS200TBQGH1A functions as an interface terminal board used with dedicated MKV turbine I/O application boards This IS200TBQGH1A Interface Terminal Board product's Mark VI Turbine Control System Series, as it is known through its full extended GE product series title, exists with a specific set of functional applications in the control and management systems of General Electric-accepting gas, steam, and wind turbine automated drive assemblies. This must be treated as quite the significant functional step up form the existing Mark V Turbine Control System Series, as the Mark VI Series added the alternative energy-based wind turbine functionality onto the gas and steam turbine environments seen earlier on with the rollout of the Mark V.
Hardware Tips and Specifications
The IS200TBQGH1A is not removable and is a box-type terminal board. The IS200TBQGH1A is built with a terminal strip with two levels of screw connectors on its surface. While the terminal strip has sixty total connectors, pins 53-60 are noted on the board surface as being “unused and internally grounded.” Other components nearby include two box resistors and four jumper switches that are marked J1 through J4. Any resistor, capacitor, diode, or even specialized integrated circuit in the normal style assembly of this IS200TBQGH1A Interface Terminal Board device here is part of a greater voltage suppression and regulation strategy standardized to the rest of this IS200TBQGH1A Interface Terminal Board product's Mark VI Turbine Control System Series. Other board components on the IS200TBQGH1A include three vertical pin (male) connectors. These are located in the right quadrant of the board in parallel with each other. Near the connectors are two lines of MOVs (metal oxide varistors.) There are two additional lines of MOVs in the left lower quadrant of the board. The board also features a line of ferrite chokes, two integrated circuits, ten resistors, over forty resistors, and over twenty diodes. Warrantied protection offered with a purchase here.
Important information regarding the installation and handling of the IS200TBQGH1A may be found through General Electric manuals and user guides. Please read all warnings and handling procedures associated with this board before beginning any kind of maintenance or installation. AX Control typically ships in-stock products within hours of your order placement. Order before 3 pm for same-day shipment, please. No originally-produced instructional manual materials have been provided on this IS200TBQGH1A Interface Terminal Board personalized product page here, which is a result of the Mark VI Series' obsolete legacy series status. With this status bein gthe case, AX is happy to still offer this IS200TBQGH1A Interface Terminal Board device for repair and replacement, with its IS200TBQGH1A Interface Terminal Board functional product number also standing to serve as a decent source of IS200TBQGH1A Interface Terminal Board hardware details, as it codes for a series of important IS200TBQGH1A Interface Terminal Board device details through its series of consecutive functional naming elements. For instance, the IS200TBQGH1A Interface Terminal Board product number starts with the IS200 series tag detailing this IS200TBQGH1A Interface Terminal Board device's normal Mark VI Series assembly as well as its domestic original manufacture location. Some other IS200TBQGH1A Interface Terminal Board qualities indicated through this medium are its:
- TBQG functional product acronym
- Group one Mark VI Series grouping
- Conformal PCB coating style
- A-rated product revision
