About the IS200TDBTH6ABC
The IS200TDBTH6ABC is a Mark VI discrete simplex board component. This type of PCB (printed circuit board) has been manufactured by General Electric for use within the company’s Mark VI Speedtronic series. The Speedtronic control series were used for the management of steam, gas, and hydro turbines of various complexity and size. The Mark VI Turbine Control System Series that this IS200TDBTH6ABC device belongs to must be defined as quite the significant functionality-minded step up from the Mark V Turbine Control System Series of just about the same full extended series title that immediately preceded it, as the Mark VI Series added the alternative energy-based wind turbine possible functional application onto the gas and steam-based traditional turbine settings made available earlier on with the rollout of the Mark V Series. This IS200TDBTH6ABC device's greater Mark VI Series is additionally seen as desirable on relevant promotional markets for its status as one of the final-produced GE Mark product series utilizing the patented Speedtronic control system technology across a number of significant processes and devices.
Hardware Tips and Specifications
The IS200TDBTH6ABC is only one of several different versions of the TDBT board available in our inventory. Please be sure to check your current board to make sure you are ordering the correct version of the TDBT board for your particular application. The IS200TDBTH6ABC includes a front faceplate like many other Mark VI components. This faceplate includes two set screws that will hold the board component in place in your rack after installation. The front faceplate also includes two connectors and three LED indicators. The faceplate is marked with the GE logo and with the board ID. The board itself carries multiple integrated circuits, two backplane connectors, test points, relays, and resistors. There are also a number of capacitors of various design. Components are located on two sides of the board. The board edges include codes that will assist you with placement and with proper wiring, although you should also consult with original documentation for the component. This includes manuals and user guides. Local customers are welcome to call us to arrange for pickup at our facility. Please call ahead with your purchase order so we can have time to pull your products from our warehouse. This limits your wait time upon arrival.
This IS200TDBTH6ABC printed circuit board product offering or PCB for short is actually not the originally-developed product of its General Electric-specified intended Mark VI Turbine Control System Series functionality, as that would have to be deemed as the IS200TDBTH6 parent PCB product notably not taking advantage of this IS200TDBTH6ABC device's unique three-fold revision table. This factoid was retrieved from the IS200TDBTH6ABC functional product number itself, which becomes a fine medium for IS200TDBTH6ABC Board hardware information given the IS200TDBTH6ABC product's Mark VI Series' lack of many online and original instructional manual materials. The IS200TDBTH6ABC functional product number codes for a number of relevant IS200TDBTH6ABC Board details through a series of consecutive functional naming chunks. For instance, the IS200TDBTH6ABC functional product number begins with an iteration of the IS200 series tag delegating this IS200TDBTH6ABC product's normal Mark VI Series assembly as well as its domestic original GE manufacture location. Some of the other important IS200TDBTH6ABC hardware qualities indicated through this primary medium include thie IS200TDBTH6ABC device's:
- TDBT functional product acronym
- Group one Mark VI Series product grouping
- Conformal PCB coating style
- Three-fold product revision table
