About the IS200TRLYH1BGF
The IS200TRLYH1BGF is a device which is called a termination relay card; most likely due to its small total product size compared to other relevant Mark VI Series product offerings. This is a sort of PCB or printed circuit board which was produced by GE or General Electric. The IS200TRLYH1BGF is a component in the Mark VI Turbine Control System series by General Electric. The Mark VI series is just one of several series which make up the Mark family of gasoline and/or steam turbine controls as you probably have been able to decipher based off of its dull extended GE product series name alone. The Mark VI Series that this IS200TRLYH1BGF product belongs to has to be considered a strong General Electric Mark product series given the fact that it is one of the lastly-developed GE Mark product series to incorporate the patented Speedtronic control system technology across a range of its different product offerings. This IS200TRLYH1BGF device is actually not the originally designed and produced device of its specific Mark VI Series functionality, as that would have to be considered the IS200TRLYH1 parent Termination Relay Card notably missing this IS200TRLYH1BGF product's full three-fold revision history.
Hardware Tips and Specifications
The IS200TRLYH1BGF circuit board is large and rectangular, containing numerous electronic components. The largest components on the IS200TRLYH1BGF are two (2) long black terminal blocks. These are devices which can hold a collection of silver metal components called terminals. The terminal blocks on the IS200TRLYH1BGF each feature twenty-four (24) of these small terminals. Each has been numbered from one to forty-eight. The center of the IS200TRLYH1BGF is occupied by a series of relays or contactors which have been arranged into a vertical line. The relays are gray and black with covers that are made from transparent plastic. Six (6) black transistors are positioned on either side of the relays on the top half of the IS200TRLYH1BGF. Paired together with each of these transistors is a red MOV or metal oxide varistor which is round in shape. One (1) additional metal oxide varistor is positioned at the lower left corner of the IS200TRLYH1BGF. Many integrated circuits can be found throughout the IS200TRLYH1BGF. Six (6) capacitors which are solid blue may be found arranged in a line to the right of the transistors and metal oxide varistors.
The Mark VI Turbine Control System Series that this IS200TRLYH1BGF device belongs to is generally not continuously being produced by its original manufacturer, as a legacy product series that was discontinued due to a manufacturer-identified series-wide functional obsolescence in one of the many years past its initial release. With this being the case, this IS200TRLYH1BGF device's functional product number can be adopted as a decently-strong primary source of IS200TRLYH1BGF Board hardware component and component specification information, as it codes for these various details through a series of General Electric-identified functional naming components, beginning with the dual-functioning IS200 series tag. The IS200 series tag at the very beginning of the IS200TRLYH1BGF functional product number is telling of this IS200TRLYH1BGF device's normal Mark VI Series assembly version as well as its domestic location of original manufacture. This dual-functional beginning tag is followed in the IS200TRLYH1BGF functional product number through an instance of the TRLY functional IS200TRLYH1BGF product acronym that was created to exist as a convenient promotional and conversational shorthand alternative to the IS200TRLYH1BGF functional product number. This is followed in the IS200TRLYH1BGF functional product number through an instance of the dual-functional H1 series grouping tag delegating this IS200TRLYH1BGF PCB's conformal PCB coating as well as its group one Mark VI Series product grouping. The final three trailing digits in the IS200TRLYH1BGF functional product number are telling of this IS200TRLYH1BGF device's three significant product revisions.
