About the IS200TSVOH1BBB
This IS200TSVOH1BBB printed circuit board product offering or PCB for short was originally designed and manufactured specifically with a functional placement in General Electric's Mark VI Turbine Control System Series in mind. The Mark VI Series that this IS200TSVOH1BBB device belongs to, as you can probably tell through its above-mentioned full extended GE product series title, exists with a specific series of functional applications in the control and management systems of General Electric-compatible gas, steam, and wind turbine automated drive assemblies. This is a significant functional upgrade on the Mark V Turbine Control System Series of just about the same full extended series title, as the Mark VI Series added the more alternative energy-friendly wind turbine possible functional application onto this IS200TSVOH1BBB device's steam and gas-based settings.
Hardware Tips and Specifications
The IS200TSVOH1BBB is one of several TSVO servo valve termination boards originally created and sold by General Electric for their GE Mark VI turbine control system. Such servo termination boards typically connect to three-coil servo actuators in most Speedtronic applications. The IS200TSVOH1BBB servo valve board is designed to use low-level signals. These signals may consist of 0 to +/-50 V dc analog signals, AC signals (rated less than 24 VAC), or 4 to 20 mA current loop signals. This board weighs approximately 2.00 pounds. While it is no longer made by or available through General Electric, we do our best to keep it within the AX Control Speedtronic inventory so we can quickly fulfill our customers’ needs. The IS200TSVOH1BBB is notched along both long edges. One long edge has notches at the corners while the other has smaller equidistant notches along its length. The board is factory drilled in three corners. Components mounted to the surface of the board carry reference designations and may also have their original manufacturer part numbers; these can lead you to datasheets for additional information.
The IS200TSVOH1BBB is populated by six d-shell connectors, two terminal strips, and several vertical plugs. It also has four transformers, transistors, relays, integrated circuits, resistors, and capacitors. Finally, the board has six jumper switches. Each jumper has six possible settings. GE Speedtronic manuals will provide you with additional details on installation procedures and handling instructions. Please read through these documents carefully before unboxing your new part from our company. If you don’t have these documents, we can help. This IS200TSVOH1BBB device's IS200TSVOH1BBB functional product number stands to act as an additional source of IS200TSVOH1BBB Board hardware component and component specification information, as it codes for a number of IS200TSVOH1BBB details through a series of consecutive functional naming chunks. For instance, this IS200TSVOH1BBB device's IS200TSVOH1BBB functional product number begins with an iteration of the dual-functional IS200 series grouping tag delegating this IS200TSVOH1BBB device's normal Mark VI Series assembly on top of its domestic original manufacture location. Some of the other IS200TSVOH1BBB details indicated in this fashion are its:
- TSVO functional product acronym
- Group one Mark VI Series grouping
- Conformal PCB coating style
- Three-fold revision table
