About the IS200TTURH1BCC
The IS200TTURH1BCC is one of several terminal boards originally manufactured by General Electric. This particular board was designed to be used as part of the company’s Mark VI and Mark VIe Speedtronic systems. These systems have been used for years for the management and control of industrial gas and steam turbines. Both systems, and consequently this board, can be used for either TMR (triple modular redundant) or Simplex applications. AX Control maintains as much on-hand stock of GE replacement parts as possible. The Mark VI Turbine Control System Series that this IS200TTURH1BCC device belongs to is actually quite the significant functionality-minded upgrade upon the Mark V Turbine Control System Series of the same full extended series name that immediately preceded it, as the Mark V Series has more restricted gas and steam-based functional settings disowning the coming Mark VI Series' added alternative energy wind turbine functional application settings.
Hardware Tips and Specifications
The IS200TTURH1BCC includes two jumper switches. These are located near one short board edge. The jumpers allow the board to be set for use with TMR (triple modular redundant) systems or with simplex systems. Each jumper controls how inputs are accepted by the board. Unfortunately, this IS200TTURH1BCC Turbine Termination Board printed circuit board product offering is not followed online by any great amount of pertinent and original instructional manual documentation, likely a result of its greater Mark VI Series' oftentimes infringed-upon product series status. With this lack being identifiable, the IS200TTURH1BCC Turbine Termination Board's IS200TTURH1BCC functional product number itself can be identified as a decently-strong primary source of IS200TTURH1BCC Board hardware component and component specification information, as it codes for various IS200TTURH1BCC Board details through a series of functional naming elements. For instance, the IS200TTURH1BCC functional product number begins with an instance of the dual-functional IS200 series tag delegating this IS200TTURH1BCC product's normal Mark VI Series assembly as well as its domestic original manufacture location. Some of the other relevant IS200TTURH1BCC Board qualities revealed in this manner include its:
- TTUR functional product abbreviation
- Conformal PCB coating style
- Group one Mark VI Series product grouping
- Three-fold significant revision table
Other board components include relays, transformers, plug connectors, and d-shell connectors. There are both male and female connectors on the board. The d-shell connectors are lined up along one long board edge with male connectors in one line and female in another. Additionally, the board has two terminal strips with screw connectors. Each of these connectors is individually numbered to help with later identification. The board also has variable resistors and traditional resistors, capacitors, and diodes. We highly recommend a thorough review of associated GE manuals and other documentation before you begin any sort of maintenance or swap-out. Be sure to read and understand all safety and handling guidelines as recommended by the OEM. This is for your safety as well as to ensure the longevity of your new equipment.
