About the IS200TTURH1CCC
The IS200TTURH1CCC is a GE Turbine Terminal Board (TTUR) for a Mark VIe system. The Mark VIe series of parts are no longer being supported by GE and may now be difficult to find. AX Control does try to keep the IS200TTURH1CCC in stock as a refurbished or new surplus part. The Mark VIe TUrbine Control System Series that this specific IS200TTURH1CCC printed circuit board product offering belongs to is something of a self-explanatory General Electric Mark product series, just given the fact that it exists with specific intended applications in wind, gas, and steam turbine management or control systems. This IS200TTURH1CCC device's greater Mark VIe Turbine Control System Series is additionally lauded on its greater figurative automated industrial marketplace considering its status as one of General Electric's lastly-designed GE Mark product series to seek to include the patented Speedtronic control system technology across a range of its different options.
Hardware Tips and Specifications
The IS200TTURH1CCC normally interfaces with a Primary Turbine Protection PCB (VTUR). The TTUR controls the TRPG (Primary Trip Terminal) board using PTUR packs. It has the ability to support Simplex and TMR applications. With this IS200TTURH1CCC device's greater Mark VIe Turbine Control System Series' legacy product series status being the case, the IS200TTURH1CCC functional product number itself can actually be identified as a decently-useful source of IS200TTURH1CCC Board hardware component and component specificaiton details; coding for these through a select series of General-Electric functional naming segments. The IS200TTURH1CCC functional product number here actually begins with an instance of a dual-functional naming segment in the IS200 series tag that indirectly names this IS200TTURH1CCC devices' normal Mark VIe Series assembly on top of its standard domestic location of original manufacture. Some of the other relevant hardware details revealed in this product's IS200TTURH1CCC functional product number include its:
- TTUR functional product acronym
- Conformal PCB coating style
- Group one Mark VIe Series product grouping
- Three-fold revision history
On the IS200TTURH1CCC, there are three female 37-pin ports and three male 37-pin connectors. The connectors are used to connect to a TRPG board. There are two terminal strips with two rows of terminals. The first terminal strip has terminals labeled 1-24. The second terminal strip has terminals labeled 25-48. There are two green 3-pin jacks and a white 4-pin jack. On the bottom corners, it has two reinforced terminal holes. On the top edge, it has four mounting divots and a small factory drilled hole. On the sides near the top corners are two large factory drilled holes. This board has two large transformers, eight red circular components, many diodes, resistors, and capacitors. When handling the IS200TTURH1CCC, it is advisable to use antistatic procedures to ensure that there isn’t any type of damage due to static shock. Keep the TTUR in antistatic packaging until it can be installed. Once it can be installed, use an antistatic wristband. For more information about this board, please refer to GEI-100575.
