About the IS200VAICH1C
The IS200VAICH1C board component is part of GE’s Mark VI turbine control system. The Mark VI Turbine Control System Series in specific is one of the most complex, most advanced Speedtronic systems created by General Electric. This IS200VAICH1C device is considered something of a versatile model of Mark VI Turbine Control System Series product offering, as it can be used to create both TMR (triple modular redundant) and Simplex control systems for industrial turbine systems (gas or steam). However, most Mark VI components are now in legacy status and are no longer supported by the OEM. We here at AX Control do our best to keep these products in our on-hand, ready-to-ship stock so we can more quickly fulfill orders when you need them most. This IS200VAICH1C device's greater Mark VI Turbine Control System Series, as it is known at length, must be considered quite the functional step up from the previous industry-standard Mark V Turbine Control System Series of a similar full extended series title, given the fact that the Mark V Series exists with a specific set of possible functional applications in the control and management systems of General Electric-compatible gas and steam turbine assemblies alone.
Hardware Tips and Specifications
The IS200VAICH1C works in conjunction with a terminal board that can accept ten inputs and two outputs. The board and its corresponding terminal board work inside a Mark VI VME processor rack, communicating with other boards within this location. Each board is individually identifiable. The IS200VAICH1C board is built with a single-width front faceplate that includes three status LEDs and two clips that will keep the unit in place once it has been installed in the rack system. The rear edge of the board has two horizontal connectors. The board itself is populated by capacitors, resistors, processor chips, and other ICs, transistors, and diodes. Most components are marked with original manufacturer marks and with their reference designation. Codes on the surface of the board will help with positioning and wiring the board. This IS200VAICH1C product is edited from the base product of its original Mark VI Series functional role through its installation of an atypical C-rated revision.
Installation and handling procedures can be sourced through original manuals or user guides from General Electric. Please follow all safety procedures recommended in these publications. Installation procedures should be read and understood before you unbox your new component. This specific IS200VAICH1C printed circuit board product offering is generally not followed by any great amount of originally-printed instructional manual materials online, which is more than likely attributable to its status as one of the more copyright infringed-upon General Electric Mark product series iterations since its rollout following the Mark V Turbine Control System Series of a similar full extended series name. Due in large part to this concerted lack of instructional documentation, the IS200VAICH1C functional product number itself can actually be isolated as a fine supplementary source of IS200VAICH1C Board hardware component and component specification information, as it codes for various relevant IS200VAICH1C Board details through a series of consecutive functional naming segments. For instance, the IS200VAICH1C product number begins with an iteration of the dual-functional IS200 series tag dictating this IS200VAICH1C PCB's normal Mark VI Series assembly on top of its more standard domestic original manufacture location. Some of the other relevant IS200VAICH1C Board qualities exposed through this medium include its:
- VAIC functional product acronym
- Group one Mark VI Series grouping
- Conformal PCB coating style
- Sole C-rated revision
