IS200VAICH1CBC

About the IS200VAICH1CBC

The IS200VAICH1CBC circuit board from General Electric functions as an Analog Input VME board within the company’s Mark VI turbine control system.  The Mark VI is one of the more advanced versions of GE’s Speedtronic industrial turbine management system.  Systems like this have been in use for over fifty years.   While the IS200VAICH1CBC component is now in legacy status and is no longer produced by the OEM, AX Control typically has on-hand stock available for purchase.

The IS200VAICH1CBC  includes an attached front faceplate.  This faceplate has a retainer pin located at each end, which will allow the board to be secured into a rack system after installation.   The faceplate includes three LED indicators that will help users know the status, run, and fail updates. Additionally, compressor stall detection from this board is executed at a rate of 200 Hz.

VAIC boards are used in both simplex and TMR (triple modular redundant) Mark VI systems.  Please be sure you are ordering the correct board for your particular application and architecture.

The IS200VAICH1CBC includes two backplane connectors located on its rear edge.  Other components located within the body of the board include four processor chips, other ICs, six relays, transistors, resistors, diodes, and capacitors.  Most components are marked for identification.

 The IS200VAICH1CBC board is a UL Class 1 Div. 2 board.  As such, it can be used in groups A, B, C, and D Hazardous locations (temp class T4 using UL-1604.)   This and other specifications about the board can be found through original documentation from the OEM like GE datasheets, GE manuals, and product user guides.
