About the IS200VCMIH1BCC
The IS200VCMIH1BCC is a printed circuit board manufactured by General Electric. It is a board component of the Mark VI turbine control system. The Mark VI is part of the Speedtronic line that has been distributed by GE in different iterations since the late 1960s. This IS200VCMIH1BCC VME Communications Interface Board device is not the originally-developed product of its specific GE Mark VI Series functionality, as that would have to be deemed as the IS200VCMIH1 Parent VME Communications Interface Board notably not making use of this IS200VCMIH1BCC VME Communications Interface Board device's three-fold revision table.
Hardware Tips and Specifications
The IS200VCMIH1BCC functions within the Mark VI system to transmit I/O data. It is part of the VME backplane and transmits internal information between I/O cards contained within its own rack system as well as those on interface modules, protection modules, control modules, and the main processor card. The IS200VCMIH1BCC uses IONet for the transmission of data between modules. IONet is a (private) special-purpose type of Ethernet used for Mark control I/O packs and controllers. This uses IEEE 1588 protocol. When a VCMI card is installed in the Control Module, it functions as the IONet bus master and communicates to slave stations using Ethernet 10Base2 network connections. A VCMI card is typically installed in each of the three control modules in a triple-redundant setup. Data from each of these cards is exchanged and voted upon before it is transmitted to the main processor card for the execution of applications.
The IS200VCMIH1BCC is designed with a connected front faceplate. This faceplate includes a single IONet port as well as multiple LED indicators. Indicators are labeled by use and are grouped together in a logical fashion. The faceplate is marked with the board number and with the GE logo. For additional information, please refer to original publications from GE like manuals or data sheets. Unfortunately, many of these originally-provided instructional manual materials are actually currently largely unavailable online, as a function of this IS200VCMIH1BCC VME Communications Interface Board device's status as a legacy GE Mark VI Series product whose greater series was discontinued in one of the many years beyond its original release. With this being true, this IS200VCMIH1BCC VME Communications Interface Board device's IS200VCMIH1BCC VME Communications Interface Board functional product number can be embraced as it was specially designed to indicate a number of important IS200VCMIH1BCC VME Communications Interface Board device specifications through its series of consecutive functional naming chunks. For instance, this IS200VCMIH1BCC VME Communications Interface Board product's IS200VCMIH1BCC VME Communications Interface Board product number begins with a typical iteration of the dual-functional IS200 series tag indicating this IS200VCMIH1BCC VME Communications Interface Board's normal Mark VI Series assembly and its domestic OG manufacture location. Some of the other important IS200VCMIH1BCC VME Communications Interface Board device information exposed in this manner include its:
- VCMI functional product acronym
- Group one Mark VI Series grouping
- Conformal PCB coating style
- Three-fold revision table
