About the IS200WDIIH3ABB
The IS200WDIIH3ABB is a component manufactured by General Electric. The board is a part of the Mark VI system. The Mark VI, which is one of GE’s Speedtronic systems, is designed for the management of steam/gas turbine systems of various complexity and size. This system can be built as a Simplex or as a TMR (triple modular redundant) system. The Mark VI Series represents a massive functional upgrade upon the Mark V Turbine Control System Series of the same full extended series title, given the fact that the Mark VI Series' intended functional application range has been expanded from before-seen gas and steam turbine management systems to include the alternative energy-focused wind turbine possible functional application. The Mark VI Series containing this IS200WDIIH3ABB product here is additionally lauded on greater promotional markets given its status as one of the last-developed GE Mark product series to incorporate the patented Speedtronic control system technology into many of its different offerings.
Hardware Tips and Specifications
The IS200WDIIH3ABB is a double-sided board that has components on both surfaces. The bottom surface has a single (male) multi-pin connector. This is marked P1. The rear surface carries the code RA/00. The front surface has an additional two connectors on the top surface. These are female jack connectors with three positions each. The plugs are placed on the right side of the board. There is a metal oxide varistor located below the plugs, which is a variable resistor. The IS200WDIIH3ABB has two lines of fast-acting fuses located parallel to the top edge of the board. These fuses are marked as FU1-FU16, as well as TR1 through TR16. There is a DIL rectifier bridge component (DN1) located in the top left corner. The IS200WDIIH3ABB is factory drilled in three corners; there is an additional four factory drill holes located in the body of the board. The board has a heat sink component located on the left side of the board. The board has ten integrated circuits, as well as capacitors and resistors. The board has several lines of diodes.There is also three lines of components placed parallel to the bottom of the board. These are labeled B2, D2, and Z2.
The actual entirety of all the IS200WDIIH3ABB Board hardware component and component specification information stored above on this IS200WDIIH3ABB personalized product page is first and foremost reminiscent of a diligent visual inspection of the IS200WDIIH3ABB printed circuit board product itself, which was deemed as necessary here given the concerning lack of originally-IS200WDIIH3ABB-pertienent instructional manual materials onine for research purposes. With this lack being identified, the IS200WDIIH3ABB functional product number may be introduced as another decently-strong source of IS200WDIIH3ABB Board hardware component and component specification information, as it codes for various relevant IS200WDIIH3ABB Board details through its characteristic selection of consecutive functional naming chunks. For example, this IS200WDIIH3ABB functional product number begins with an iteration of the dual-functional IS200 series tag delegating this IS200WDIIH3ABB product's normal Mark VI Series assembly version on top of its domestic manufacture location, specifically in General Electric's Salem, Virginia factory plant location. Some of the other relevant IS200WDIIH3ABB Board details indicated through this medium include its:
- WDII functional product acronym
- Group 3 Mark VI Series grouping
- Conformal PCB coating style
- Three-fold revision table
