IS200WEMAH1APR2

About the IS200WEMAH1APR2

The IS200WEMAH1APR2 circuit board is a General Electric board component.  This is a 1-slot turbine control part that is designed to fit into a GE Mark VI 13- or 21- slot rack system.  The Mark VI was one of the final Speedtronic turbine control systems released by General Electric.  This flexible system offers design options that make it usable for both large and small industrial turbine systems.  Users can create a simplex MKVI system for less complex units, or build a triple modular redundant control system if more complexity is required.

The IS200WEMAH1APR2 is conformal coated and uses surface mount technology.   The board has four standoffs located near its center that can be used to add an additional auxiliary board.  Near these are two connection ports that will facilitate communication between the two boards.

The IS200WEMAH1APR2 has a number of different components on its surface.  These include a line of heat sinks to dissipate heat buildup before it can affect components, terminal blocks for connection points, plugs for adding connections to the board, vertical pin header connectors, relays, transistors, capacitors, diodes, and resistors.  The board has reference designators printed close to most components to make identification easier.

The IS200WEMAH1APR2 board is marked with the GE logo and is factory drilled within its body and along the edges of the board.  For information regarding installation or handling, refer to associated manuals or user guides.  These will provide additional guidance and should be read and thoroughly understood before beginning any work.  Our team can sometimes help with sourcing this information.
