About the IS2020RKPSG1A
The IS2020RKPSG1A is a module component manufactured by GE for the Mark VI. Created for steam or gas turbine management, the Mark VI was one of the last of the Speedtronic systems distributed by General Electric, but has been popularly resold and refurbished in recent years as it remains a perfectly viable, industry-certified option for most factory automation requirements. The Mark VI Turbine Control System Series that this IS2020RKPSG1A device belongs to has to be characterized as quite the significant functional upgrade upon the previous industry-standard Mark V Turbine Control System Series of the same full extended GE Mark product series name, as the Mark VI Series added an alternative energy-based wind turbine control system functional application upon the Mark V Series' established gas and steam turbine applications. The Mark VI Series that this IS2020RKPSG1A device belongs to is additionally lauded given its status as one of General Electric's final-developed Mark product series wielding the patented Speedtronic control system technology through a number of unique product offerings.
Hardware Tips and Components
The IS2020RKPSG1A is a self-contained VME rack power supply module. The front faceplate of this module is marked “Power Supply.” The faceplate has an open (waffled) area to allow air movement into the component. It has three locations at the bottom of the faceplate for recording the GE catalog number, the revision number, and the serial number. This part of the module also includes three LED indicators (green, red, and yellow) as well as a single toggle switch. This singualar toggle switch is the only user control on the module, and can be toggled to reset faults. These faults fall into three categories: those that require a reset action to clear, those that result in an output shutdown, and those that result in permanent failure of the power supply. This module has a 400 W output rating and a 125 Vdc input voltage an has nine outputs; including three +28V remote outputs, a single PS335 output, and five +28V outputs. The IS2020RKPSG1A has a fan as part of its design. Due to the open nature of this module's faceplate, however, the fan is only used when the module is mounted into the rack position. This fan is powered from the top connector.
Here at AX Control, we maintain a million dollar inventory of industrial automation parts. All our products are competitively priced. AX Control can save you even more money through programs like surplus purchasing and our warranty programs. Click on the page links available above to find out more. Given the fact that this IS2020RKPSG1A product's greater Mark VI Turbine Control System Series is not accompanied online by any viable instructional manual materials, all of the previously-stored information here has been reminiscent of a diligent technician-led visual inspection of the IS2020RKPSG1A product itself. One other strong alternative source of IS2020RKPSG1A Board hardware information can be considered to exist as its IS2020RKPSG1A functional product number that was specially designed by GE to demonstrate a number of relevant IS2020RKPSG1A Board details through a series of consecutive functional naming chunks. For example, this specific IS2020RKPSG1A functional product number begins with the dual-functional IS2020 series tag delegating this IS2020RKPSG1A PCB's normal Mark VI Series assembly as well as its domestic original manufacture location. Some of the other central IS2020RKPSG1A Board qualities exposed like this include this RKPS-abbreviated device's:
- RKPS functional product abbreviation
- Normal PCB coating style
- Group one Mark VI Series grouping
- A-rated functional product revision
