IS210BPPCH1AC

4.50 (2)
Click a star to rate this product

4.50 (2)
Click a star to rate this product

The BPPC Processor IS210BPPCH1AC was designed to work in the Mark VI Series with the UCPA processor. This model can accept serial interfaces at a nominal voltage of 12 VDC. This model is equipped with an internal temperature sensor.

Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS210BPPCH1AC to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS210BPPCH1AC
SKU: IS210BPPCH1ACGBTC

Manufacturer: GE Boards & Turbine Control
Series: Mark VI IS200

Description
Repairs
Warranty
Manuals

IS210BPPCH1AC Technical Specifications

Diagnostic Signals to UCPA	ATTN
Features	Local CPU Power Supplies
Flashing Patterns Quantity	7 for Red ATTN and 4 for Green ATTN
LED Colors	Red and Green
Manual	GEH-6721; Vol I, II, and III
Model Type	Internal UCPA Processor
Nominal Voltage Range	9-16 VDC with Voltage at 12 VDC
Processor Board Compatibility	YAICS1B, YDIAS1B, YDOAS1B, PVIBH1B, YVIBS1B and More

About the IS210BPPCH1AC

The IS210BPPCH1AC from General Electric functions within the Mark VIe Speedtronic system as an I/O Pack Processor Board for the UCPA. This Speedtronic component has newer components and offers upgraded capabilities in comparison to the previously used BPPB input and output packs. This I/O pack is designed for use with Mark VIe systems. If you require I/O packs for a Mark VIeS system, look for BPPCS1 boards instead of BPPCH1.

The IS210BPPCH1AC circuit board can be used within either Dual or TMR (triple modular redundant) systems. Its flexibility allows use with other BPPC packs or with older BPPB components. Auto Reconfiguration from BPPB to BPPC is typically supported except in certain circumstances.

Some of the main features of the IS210BPPCH1AC board are the reset circuits with the hardware watchdog timer as well as status indication LEDs. There are two primary LED color flashes that work with this model which are green and red ATTN LED.

The IS210BPPCH1AC is designed to support branding. This is a ToolboxST application process that allows users to mark sets of code as being acceptable and necessary for specific purposes.

The Mark VIe Speedtronic system offers a flexible platform with high-speed I/O that can be used for Simplex, Dual, or TMR configurations. It works in conjunction with GE’s ControlST Software Suite, which includes its proprietary ToolboxST application. Refer to GE manuals for additional information about this board as well as information about the associated control system, its controllers, switches, IONet, and other architecture points.

Reviews For IS210BPPCH1AC

Internal Review

(5.0)

Many I/O packs within the Mark VIe have naturally migrated from BPPB I/O to BPPC. BPPC I/O packs for the Mark VIe require ControlST V04.04 (minimum) and I/O upgrade V05.01. Minimum firmware for any particular BPPC-based I/O can be found in the Compatibility subsections of GEH-6721 Vol III. --AX Control Tech Team.

Repair Services For IS210BPPCH1AC

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	$720

Our highly skilled technicians can repair your IS210BPPCH1AC. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
