About the IS210BPPCH1AD
The IS210BPPCH1AD circuit board is an I/O pack processor board from General Electric. This is one of several BPPC boards available within AX Control’s inventory, each with minor variations. These boards are designed to be used within various I/O packs that fit into GE’s Mark VIe turbine control system. Please note these are note designed for the similar Mark VIeS system. The Mark VI Series that this IS210BPPCH1AD product belongs to, as you can probably tell based off its full extended GE product series name as the Mark VI Turbine Control System Series, exists with a set of specific functional applications in both the control systems and management systems of General Electric-accepting gas, steam, and wind turbine automated drive assemblies. This is seen as quite the major functional upgrade upon the Mark V Turbine Control System Series of the same name that came before it, as the mark V Series specifically pertained to the control and management systems of gas and steam turbine assemblies alone.
Hardware Tips and Specifications
The IS210BPPCH1AD board is factory drilled at each corner. The board mounts to a larger circuit board using standoffs with screw mounts. The screw mounts are close to rounded cutouts located along the long board sides. The IS210BPPCH1AD is a double-sided board that uses SMT technology to allow for maximum use of space. The top side of the board includes two Ethernet ports, a small inductor or choke, diodes, resistors, capacitors, transistors, and multiple integrated circuits. It also has several resistor network arrays. The bottom surface is primarily taken up by capacitors, resistors, and diodes. Most of these previously-listed hardware components in this IS210BPPCH1AD printed circuit board product offering's normal Mark VI Series assembly are simply part of a greater voltage suppression and regulation strategy that has been standardized to the Mark VI Turbine Control System Series as a whole. This IS210BPPCH1AD printed circuit board or PCB for short is actually not the originally-produced device of its specific Mark VI Turbine Control System Series functional role at all, as that would have to be considered the IS210BPPCH1 parent printed circuit board notably not utilizing this IS210BPPCH1AD product's signature two-fold product revision history. This is quite the abnormal number of Mark VI Series revisions for any given product.
Refer to GE manuals to verify all locations where this board can be used. BPPC boards show up in a number of different I/O packs within the Mark VIe turbine system, but this particular board may not apply to all these locations. Manuals will also provide you with extended information regarding handling, installation, and maintenance of the component. AX Control ships products every day we are open, and typically can ship within a few hours of your purchase order’s arrival. Let our team know if you have special shipping requirements, including expedited shipping. Local customers can arrange to pick up their products at our facility or can send their private courier for faster turnaround. This IS210BPPCH1AD printed circuit board product offering from General Electric is not surrounded by many originally-pertinent instructional manual materials online; likely a function of its greater mark VI Series' status as one of the final-developed GE Mark product series to incorporate the patented Speedtronic control system technology into many of its different offerings. With this being the case, the IS210BPPCH1AD functional product number itself can come into the picture as a fine supplemental source of IS210BPPCH1AD Board hardware component and component specification information; coding for various IS210BPPCH1AD Board details in a series of consecutive functional naming components. For instance, the IS210BPPCH1AD functional product number begins with an instance of the dual-functional IS210 series tag indirectly delegating this IS210BPPCH1AD product's special modular Mark VI Series assembly version on top of its even more standardized domestic location of original General Electric manufacture. Some of the other pertinent hardware details revealed in this fashion include this IS210BPPCH1AD product's:
- BPPC functional product acronym
- Conformal PCB coating style
- Group one Mark VI Series product grouping
- Two-fold significant revision history
