About the IS220PAICH1A
Described as an Analog I/O Pack the IS220PAICH1A model has been approved to be used in hazardous and non-hazardous locations alike, which given birth to its HazLoc Mark VI Turbine Control System Series Subseries classification. The broader Mark VI Turbine Control System Series that this IS220PAICH1A Analog I/O Pack modular assembly product offering belongs to, as partially evidenced through its GE-developed full extended product series title, exists with a specific set of possible functional product applications in the control and management systems of GE-compatible gas, steam, and wind turbine automated drive assemblies. This must be highlighted as quite the important functional improvement upon the previously rolled-out industry standard of the Mark V Turbine Control System Series, as this IS220PAICH1A Analog I/O Pack product's Mark VI Series added the more alternative energy-focused wind turbine possible functional application onto the gas and steam turbine settings established originally through the Mark V.
Hardware Tips and Specifications
On the front of the model, there are four indicators. There is also one port on the bottom which is described as an I/O port. There are several voltages that can be used with the PAIC pack, the minimum voltage of the PAIC pack is twenty-seven point four volts of direct current. There are a variety of certifications associated with the IS220PAICH1A pack due to its ability to be used in a number of locations, some of which are hazardous locations, class one zone two group IIC, class one division two groups A, B, C, D, and ATEX zone two, group IIC and non-hazardous locations as well. The following certifications are used for the locations, UL E207685, and UL DEMKO 12 ATEX 1114875X, please take into account that the UL E207685 certification is used in numerous locations. There are three models that can be used with the IS220PAICH1A unit which are the IS200STAIH1A and IS200STAIH2A as well as the IS20TBAIH1C model. All of these models are referred to are known as input-output terminal boards. This IS220PAICH1A Analog I/O Pack device is not the originally-developed device of its particular Mark VI Series functionality; that would be the IS220PAICH1 parent Analog I/O Pack not taking advantage of this IS220PAICH1A Analog I/O Pack device's sole A-rated functional revision.
The typical location for the PAIC I/O pack will be in one of the two available VME racks which are the thirteen or twenty-one slot racks. Please note that this unit will typically be used with a triple modular redundant architecture system. With the TMR system, there is an individual control module, I/O net, and main processor card. This IS220PAICH1A Analog I/O Pack device's IS220PAICH1A Analog I/O Pack functional product number was actually specifically designed by General Electric to indicate a number of important IS220PAICH1A Analog I/O Pack hardware qualities, including its special modular Mark VI Series assembly, PAIC functional product abbreviation, conformal style of PCB protective chemical coating, group one Mark VI Series product grouping, and finally its sole A-rated functional style of Mark VI Series product revision. This IS220PAICH1A Analog I/O Pack device is well-contextualized online within a wealth of originally-designed instructional manual materials. These materials specifically consider this IS220PAICH1A Analog I/O Pack printed circuit board modular assembly product offering's basic voltage specifications in a chart form, with these including the:
- 28.6 V dc Power Supply Voltage with a 0.49 A dc Current
- 10 V dc Max 1-8 Input Voltage with a 20 mA dc Max Current
- 5 V dc 9-10 Max Voltage with a 20 mA dc Max Current
- 16.3 V dc Outputs Max Voltage with a 20 mA dc Max Current
- 25.2 V d Analog Transmitter Max Voltage with a 21 mA dc Max Current
