About the IS210WSVOH1A
As mentioned above, this IS210WSVOH1A printed circuit board was originally manufactured by GE Energy, and is more specifically-definable by its original instructional manual-specified functional product description as a Servo Driver Board. GE Energy, the company responsible for the manufacture of all Mark VIe Series products, actually exists as a subsidiary manufacturer for the greater industry-respected retailer giant General Electric. This IS210WSVOH1A printed circuit board or PCB for short is actually a modified version of a different, pre-existing Mark VIe Series printed circuit board; altering the IS210WSVOH1 PCB through its addition of a singular, A-rated functional product revision.
Hardware Tips and Specifications
The IS210WSVOH1A Servo Driver Board is not described in great detail in available instructional manual materials on the internet, perhaps due to this IS210WSVOH1A printed circuit board's placement in the specialized and relatively newly-developed Mark VIe Series. With this being true, a lot of pertinent information to the IS210WSVOH1A board can be gleaned from a thorough visual inspection of the PCB, paired with information attainable from fringe Mark VIe Series manual materials and the functional IS210WSVOH1A product number. The most precise functionality of this IS210WSVOH1A PCB is found in its functional description as a Servo Driver Board.
In visual inspection, a primarily-noticeable hardware element adopted in the IS210WSVOH1A board assembly is identifiable as its bulky metal backplane, which must have been included in its assembly for installation purposes. The presence of this thick metal PCB backplane points to this model's likely classification as a standard-mounted printed circuit board that doesn't necessitate a DIN-rail for installation. This IS210WSVOH1A PCB features other identifiable hardware components upon visual inspection, including a standard number of voltage-regulating hardware components, including resistors, transistors, diodes, and integrated circuits.
This IS210WSVOH1A Board is a crucial component board in several Mark VIe Series modular assemblies, as indicated in product-specific instructional manuals. This IS210WSVOH1A Servo Driver Board is a component board incorporated into assemblies such as:
- The IS230TSVCH1A and IS230TSVCH2A modular assemblies, in which the IS210WSVOH1A PCB appears in a sole quantity
- The IS230TSVCH3A and IS230TSVCH4A modular assemblies, in which this Servo Driver Board appears three times per modular assembly.
All of the various hardware components and specifications mentioned above should be well-protected beneath this IS210WSVOH1A circuit board's conformal style of PCB protective coating, which was discovered upon a breakdown of the functional IS210WSVOH1A product number. This individualized IS210WSVOH1A product number yields a high amount of product-specific hardware information, including this Servo Driver Board's special assembly version, WSVO functional acronym, group one Mark VIe Series groupining alignment, and its singular, A-rated functional product revision.
