About the IS420UCSBH4A
Controller IS420UCSBH4A is another UCSB controller produced by General Electric for the Mark VIe Turbine Control System Series. The Mark VIe Series that this IS420UCSBH4A printed circuit board product offering was manufactured for has specific applications in the control and management systems of popular and compatible gas, steam, and wid turbine automated drive assemblies. This IS420UCSBH4A device's greater Mark VIe Turbine Control System Series is additionally definable as one of the final-developed General Electric Mark product series to introduced their patented Speedtronic control system technology across a range of its different offerings, which greatly increases the overall market demand of the IS420UCSBH4A PCB overall. This IS420UCSBH4A device is not definable as a typical Mark VIe Series printed circuit board product offering; it is really a modular assembly as indicated by the initial series tag in the IS420UCSBH4A functional product number.
Hardware Tips and Specifications
This controller is described as being able to work in the EX2100e, LS2100e, and Mark VIe series that operate on a 1066 MHz EP80579 Intel Processor. The EP80579 processor is used to help in applications that require high reliability as well as high speeds. This model is similar to the previous UCSB controllers except for the processor used which is mentioned above, the controller all use the same processor type but operate on a different MHz. This IS420UCSBH4A device's special modular Mark VIe Turbine Control System Series assembly essentially consists of interior pieces of circuitry and hardware components contained inside a sturdy black plastic exterior chassis. This chassis is permeated in several locations on a narrow side by several obvious ethernet-style connector ports; each of which should be labeled with a factory-printed nomenclature label. A metal backplane connector has been supplied on the IS420UCSBH4A module's other narrow side, for convenient IS420UCSBH4A module installation, possibly in the Mark VIe Series' standard VME Rack Mounting and Installation assembly. This IS420UCSBH4A device's functional product number reveals a swathe of other relevant hardware information including this IS420UCSBH4A device's special modular Mark VIe Series assembly, UCSB functional product abbreviation, conformal PCB coating style, group four Mark VIe Series product grouping, and finally its A-rated primary functional product revision.
The IS420UCSBH4A controller is similar to the UCSC controller that is also in the Mark VIe Series, the difference between the group of controllers is the hardware, but they do have some similarities pertaining to the advantages of the controller. Some of the advantages of this controller are that is a single module and it has flash memory which can be conveniently updated for the user's needs. The locations and the certifications needed to operate this controller are the same as the previous models, the controller can be used in hazardous and non-hazardous locations with UL E207685 and UL DEMKO 12 ATEX 1114875X certifications. All information regarding the locations and their required certifications can be obtained from the GEH-6725 Mark VIe/VIeS Controls Equipment HazLoc Instruction Guide on page 112. The IS420UCSBH4A controller is readily available in used or new surplus for any of AX Control customers' needs. AX Controls' team of specialists can repair this controller for you if needed. If you would like a repair quote please contact the sales department at AX Control by phone or email to obtain this information.
