6KAF343001E$A1

Product Description

The General Electric Fuji Electric 6KAF343001E$A1 is a member of the AF-300E$ series. This 3 phase, 1 horsepower drive inputs 460 VAC with a frequency of 50/60Hz, while outputting 380-460 VAC with a frequency range of 0.2-400Hz. Pulse Width Modulation (PWM) Scalar power control integration offers better operational interfacing and performance. The front plate of the drive features a mounted factory installed keypad.

Housed in a NEMA 1 enclosure, 6KAF343001E$A1 is available for indoor open or panel mounting. The drive weighs 8.4 pounds and measures 10.24in (H) x 5.91in (W) x 5.71in (D). The mounted keypad panel found on the front of the drive features 8 dual function keys, a digital monitor, and an LCD graphic display. This panel can be easily removed for remote operation and display by loosening the two mounting screws securing it to the face.

Included keys on the keypad panel are a PROGRAM key, a FUNCTION key, a SHIFT key, a RUN key, a STOP key, a RESET key, and UP/DOWN keys. For easier viewing the LCD brightness on the screen is adjustable to accommodate a variety of working environments.

Drive longevity can be ensured by following all proper storage and operational protocols. The ambient temperature of the facility that houses 6KAF343001E$A1 must range from -10℃ to 50℃, or 14℉ to 122℉. Should the temperature climb higher than 40℃, or 104℉, remove the ventilation covers to prevent the device from overheating. The rear cooling fins can reach temperatures of 90℃, or 194℉, so proper installation is imperative to prevent accidents. All installation and safety protocols are outlined in the corresponding instruction manual.
